37
EN
Both the start and end time can be set for this charging time period. The starting time can
be deselected as required; the charging time then bases itself exclusively on the specified
charge end time following a manual charge start.
When applying the settings, the user is guided through the menu in much the same way
as a wizard function.
Use the "Up/Down" keys to select the desired parameter (e.g. "Cells").
Use the "Pause/Start" key to confirm the parameter.
Use the "Up/Down" keys to set the desired value (e.g. "24" for the number of battery
cells).
Use the "Pause/Start" key to confirm what you have entered.
If one or more relevant settings are changed for the charging process in configuration
mode, you will once again be prompted to confirm acceptance of the changed settings
when exiting configuration mode.
The following settings need to be confirmed when exiting configuration mode:
- Characteristic
- Battery capacity in Ah (excluding the RI characteristic)
- Number of cells
- Equalising charge ON/OFF
- CAN protocol
Example:
Changing the characteristic from 3 - UI (Pb-
WET) to 6 - RI (Pb-WET).
If the setting is not confirmed, the charger
returns to configuration mode and the set-
ting can be changed to the desired value.
Settings Below is a detailed description of the "Settings" menu item for the "Charging settings"
menu item discussed above. Navigation is performed as described in the "Configuration
mode" section.
A list appears with the following selection options:
4
5
