18
Dimensions
Removing the
pallet
Remove the device from the pallet after de-
livery.
WARNING!
Danger resulting from operating the de-
vice on the pallet.
This may result in serious injury and dama-
ge to property.
► Operating the device on the pallet is not
permitted.
► After setup, the device must be secured
to the floor or wall using the wall bracket
bar.
► Detailed information on the wall bracket
bar can be found in the "Wall mounting"
section.
mm (in.)
780 (30.71) 369 (14.53)
1090 (42.91)
110 (4.33)
600 (23.62)
145 (5.71)
