59
EN
Main charge fin-
ished
The "Main charge finished" option is suitable for actuating a signal lamp for instance. When
the main charge phase finishes, the corresponding relay picks up automatically.
Common error
message
The "Common error message" option is suitable for actuating a signal lamp for instance.
Each time an error is detected, the relevant relay picks up automatically.
Common error +
warning
In the same way as for the "Common error" function, the corresponding relay trips as soon
as an error or warning is detected.
Signal lamp As an alternative to the charging lights, one or more suitable lamps can be connected to
the relay board to indicate the state of charge or operating status of the charger. These
lamps can be designed for a voltage of up to 30 V DC or up to 250 V AC on a starpoint-
earthed network.
If the lamp circuit is potential-free, then the switching current must not exceed 4 A. A lamp
that is actuated by the 230 V supply relay must be operated with an output current of max.
1 A.
Immobiliser de-
vice
If the charger is built into a vehicle as an on-board device, the optional immobiliser device
will prevent the vehicle from being started unintentionally whilst charging is taking place.
This protects the vehicle, the battery and the charger leads from damage.
As soon as the vehicle is connected to the mains supply, the corresponding relay picks up
and blocks the ignition signal for instance. Another example is the actuation of a suitable
signal lamp to convey the message visually that charging is currently in progress.
Battery cooled
down
The corresponding relay switches automatically once the time set in the menu has passed.
External air pump
- electrolyte circu-
lation
This option enables an external air pump to be activated by a relay contact in the sense of
the "electrolyte circulation" option.
LED strip The LED strip acts as a status indicator and lights up in the same colours as the display
elements on the control panel. An LED strip including a diffuser is installed in the gap be-
tween the front wall and upper part of the housing.
