62
Technical data
Selectiva 30 kW
Mains voltage (-10%/+30%)
1)
Optional:
3~ NPE 400 V/50/60 Hz
3~ PE 400 V/50/60 Hz
Mains fuse protection 63 A
Minimum mains lead cross section 10 mm² (0.0155 in²)
Leakage current
2)
360 VAC - 3.3 mA A.C.
400 VAC - 4.2 mA A.C.
520 VAC - 4.8 mA A.C.
Duty cycle 100%
EMC device class B
Standby consumption
Selectiva 8250/8300
Selectiva 8375
25.1 W
25.9 W
Protection class 1
Max. permitted mains impedance Z
max
on PCC
3)
Selectiva 8250
Selectiva 8300
Selectiva 8375
59 mOhm
51 mOhm
41 mOhm
Degree of protection
4)
IP 20
Overvoltage category III
Operating temperature
5)
-20°C to +40°C
(-4°F to 104°F)
Storage temperature -25°C to +80°C
(-13°F to 176°F)
Relative humidity maximum 85%
Maximum altitude above sea level 2000 m (6561 ft)
Mark of conformity according to rating plate
Product standard EN62477-1
Dimensions L x W x H 780 x 369 x 1090 mm
(30.71 x 14.53 x 42.91 in.)
Weight (with standard mains and charging leads) 104 kg (229.28 lb)
Degree of contamination 3
1) The device is approved for operation on neutral-earthed mains networks with a max-
imum outer conductor nominal voltage of 400 V.
2) The minimum cross section of the ground conductor must conform to the local safety
requirements for electrical installations that place high demands on the ground con-
ductor. The device has an increased leakage current. This must be taken into account
in accordance with national regulations when installing the device.
3) Interface to a 230/400 V and 50 Hz public grid.
4) For indoor use only, do not expose to rain or snow.
5) A high ambient temperature may result in power degradation (derating).
