4
Press the Mode button to select the desired MIG/MAG mode:
2-step mode
4-step mode
Special 4-step mode (aluminium welding start-up)
Spot welding
In MIG/MAG standard manual welding, special 4-step mode corresponds to conven-
tional 4-step mode.
The settings for the parameters for Spot welding mode are described in the Setup
menu.
NOTE!
Parameters that have been set on a system component control panel (e.g. wire
feed unit or remote control) might not be able to be changed on the power
source control panel.
5
Press the Parameter selection button and select the wire feed speed parameter
6
Use the adjusting dial to set the desired value for the wire feed speed
7
Press the Parameter selection button and select the welding voltage parameter
8
Use the adjusting dial to set the desired value for the welding voltage
The parameter value is displayed in the digital display located above it.
All welding parameter set values that have been set using the adjusting dial or but-
tons on the welding torch remain stored until the next time they are changed. This is
true even if the power source is switched off and on again in the meantime
To display the actual welding current during welding:
- press the Parameter selection button and select the welding current parameter
- the actual welding current is displayed on the digital display during welding
9
Open the gas cylinder valve
10
Set the shielding gas flow rate:
Press the Gas test button
- Turn the adjusting screw on the underside of the pressure regulator until the
pressure gauge shows the required gas flow rate
CAUTION!
Risk of injury and damage from electric shock and from the wire electrode
emerging from the torch.
When pressing the torch trigger:
▶
keep the torch away from your face and body
▶
do not point the welding torch at people
▶
make sure that the wire electrode does not touch any electrically conducting or
earthed (grounded) parts, such as the housing, etc.
11
Press the torch trigger and start welding
Corrections dur-
ing welding
In order to obtain the best possible welding results, the following parameters can be cor-
rected in certain circumstances:
105
EN
