MMA welding
Safety
WARNING!
Danger from incorrect operation.
Possible serious injury and damage to property.
â–¶
Do not use the functions described here until you have read and completely under-
stood these Operating Instructions.
â–¶
Do not use the functions described here until you have fully read and understood all
of the Operating Instructions for the system components, in particular the safety
rules!
WARNING!
An electric shock can be fatal.
If the power source is connected to the mains electricity supply during installation, there
is a high risk of very serious injury and damage.
â–¶
Before carrying out any work on the device make sure that the power source mains
switch is in the "O" position
â–¶
Before carrying out any work on the device make sure that the power source is
unplugged from the mains
Prerequisite Manual metal arc (MMA) welding is only possible in conjunction with the Comfort, US,
TIME 5000 Digital and CMT control panels.
The inputs required for MMA welding are described by reference to the Comfort control
panel.
Preparation
1
Move the mains switch to the "O" position
2
Disconnect the mains plug
3
Remove the MIG/MAG welding torch
NOTE!
Check the rod electrode packaging to determine whether the rod electrodes
are for (+) or (-) welding.
4
Plug the grounding (earthing) cable into either the (-) or the (+) current socket,
depending on the type of electrode, and latch it in firmly
5
Use the other end of the grounding (earthing) cable to establish a connection to the
workpiece
6
Plug the bayonet current plug of the electrode holder cable into the free current
socket with the opposite polarity, according to the type of electrode, and twist it
clockwise to latch it in place
7
Plug in the mains plug
121
EN
