4.6 ALARMS
An alarm will be displayed once a fault occurs.
4.61 Siemens Alarms
1. If a familiar alarm number / description appears carefully check the machine and resolve the cause of the alarm.
2. If you are unfamiliar with the alarm in question, proceed to the alarm list as follows:
a. Press MENU SELECT
b. Select DIAGNOSTICS
c. Select ALARM LIST
3. *Once “ALARM LIST” has been selected, press HELP key and additional information will be provided on the
control screen.
4.62 Fryer PLC Alarms and Descriptions
There are certain PLC alarms in the 700000 range which are not in the HELP screen. These are FRYER Machine
specific alarms that are for optional equipment installed on the machine. The alarms are listed below:
700000 ATC CAROUSEL NOT REFERENCED: EXECUTE M61
700001 LOW WAY LUBE [I32.6]
700002 LOW AIR PRESSURE [I32.2]
700003 HOME REQUIRED! PRESS CYCLE START
700004 PROBE ERROR / SIGNAL LOSS
700005 GEAR CHANGE FAULT
700006 SPINDLE OUT OF GEAR
700008 CHILLER FAULT
700009 HYDRAULIC PRESSURE FAULT
700011 THRU SPINDLE COOLANT FAULT, CHECK COOLANT SUPPLY
700013 EMERGENCY STOP PRESSED DURING TOOL CHANGE
700014 COUNTER-BALANCE CYLINDER PRESSURE LOW!
700015 ATC CAROUSEL TIMED OUT-CHECK THERMAL MCCAR
700016 CAROUSEL CANNOT INDEX POT NOT RETRACTED
700024 M52-TOOL POT DOWN TIMED OUT
700025 M53-TOOL POT UP TIMED OUT
700026 M69 CAUSED SERVO OFF
700027 M62 TIMED OUT CHECK TC HEIGHT,ORIENT,THERMAL MCATC
700028 M63 TIMED OUT CHECK THERMAL MCATC
700029 M54 DRAWBAR ON TIMED OUT
700030 M55 DRAWBAR OFF TIMED OUT
700032 CONTOUR HANDWHEEL ACTIVE
700033 Z MOTION AND ATC ARM NOT AT HOME POSITION
700034 RESET SUPPRESSED UNTIL TOOL CHANGE COMPLETION
700035 HOME RETURN: DEPRESS CYCLE START
700037 REPLACE PROBE BATTERY
700038 TOOL SETTER ACTIVE
700039 PART PROBE ACTIVE
700040 WAY OILER PRESSURE FAULT
700041 DOOR IS OPEN ~ CLOSE DOOR; PRESS CYCLE START TO CONTINUE
