FRYER CM Series - CM-15 Machine Assembly Parts List

45
6.9 CM-15 MACHINE ASSEMBLY PARTS LIST
ITEM
PART NO.
DESCRIPTION
SPECIFICATION
QTY
1
253002F
Base
100
1
2
HD673
Oil pipe
1
3
Coupler
M6
1
4
HW104
Spring Washer
M6
4
5
HS231
Hex. Socket Head Screw
M6*P1*L25
4
6
253011F
Y Ballscrews
1
8
253007J
Motor Bracket Y
1
9
HW105
Spring Washer
M8
4
10
HS244
Hex. Socket Head Screw
M8*P1.25*L30
4
11
HP303
Angle Pin
ø 5*38L
2
12
253093
Motor Bracket Cover
1
13
HT003
Cross Round Head Screw
M6*P1*L10
4
14
Oil Seal
40 ø * ø 28*8t
1
15
253012A
Space Ring
1
16
CA7204C
Angular bearing
7204-P5
2
17
253006
Space Ring
1
18
253010A
Nut
YSF-M20XP1.0
1
19
253008
Press Board
1
20
HW104
Spring Washer
M6
4
21
HS230
Hex. Socket Head Screw
M6*P1*L20
4
22
253032E
Connecting shaft
1
26
HW104
Spring Washer
M6
4
27
HS231
Hex. Socket Head Screw
M6*P1*L25
4
28
HS220
Hex. Socket Head Screw
M5*P0.8*L20
2
29
253117B
Bull block Y
2
30
253018
Bearing Seat
1
31
HW104
Spring Washer
M6
4
32
HS231
Hex. Socket Head Screw
M6*P1*L25
4
33
HP303
Angle Pin
ø 6
2
34
CA6003ZZ
Ball Bearing
6003ZZ
1
35
HCK04
C-Retainer Ring
S17
1
36
253150B
Y Linear Guideway
2
37
HS230
Hex. Socket Head Screw
M6*P1*L20
16
38
HS231
Hex. Socket Head Screw
M6*P1*L25
20
39
253153
Wedge
20
40
HS220
Hex. Socket Head Screw
M5*P0.8*L20
20
41
Coupler
2
42
HS231
Hex. Socket Head Screw
M6*P1*L25
2
43
Oil pipe
2
44
Oil pipe
4
59
HB302
Dust Cover
ø 35
1
60
HS231
Hex. Socket Head Screw
M6*P1*L25
4
61
HW104
Spring Washer
M6
4
