FRYER CM Series - Page 47

46
62
253034
Bearing Seat
1
63
253117B
Bull block X
2
64
HS220
Hex. Socket Head Screw
M5*P0.8*L20
2
65
HCS06
C-Retainer Ring
S17
1
66
CA6003ZZ
Ball Bearing
6003ZZ
1
67
253003B
Center Base
1
70
253091D
Switch bracket
1
71
HW004
Washer
M6* ø 13*T1
2
72
HS230
Hex. Socket Head Screw
M6*P1*L20
2
74
HW004
Washer
M6* ø 13*T1
2
75
HS229
Hex. Socket Head Screw
M6*P1*L15
2
78
HS231
Hex. Socket Head Screw
M6*P1*L25
4
79
HW104
Spring Washer
M6
4
80
Oil pipe
1
81
Coupler
M6
1
82
253017C
X Ballscrews
1
84
253004
Acme Nut Base
1
85
HW104
Spring Washer
M6
4
86
HS231
Hex. Socket Head Screw
M6*P1*L25
4
87
HP303
Angle Pin
ø 5*38L
2
88
253015J
Motor bracket X
1
89
HW105
Spring Washer
M8
4
90
HS244
Hex. Socket Head Screw
M8*P1.25*L30
4
91
HP303
Angle Pin
ø 5*38L
2
92
Oil Seal
40 ø * ø 28*8t
1
93
253012A
Space Ring
1
94
CA7204C
Angular bearing
7204-P5
2
95
253006
Space Ring
1
96
253010A
Nut
YSF-M20XP1
1
97
253008
Press Board
1
98
HW104
Spring Washer
M6
4
99
HS230
Hex. Socket Head Screw
M6*P1*L20
4
100
253032B
Connecting shaft
1
104
HW104
Spring Washer
M6
4
105
HS230
Hex. Socket Head Screw
M6*P1*20L
4
112
HT003
Cross Round Head Screw
M6*P1*L10
4
113
253158E
Motor Cover
1
114
253208
Plate
1
115
253091A
Switch bracket
1
116
HW004
Washer
M6* ø 13*IT
2
117
HS229
Hex. Socket Head Screw
M6*P1*L15
2
121
HW004
Washer
M6* ø 13*T1
2
122
HS229
Hex. Socket Head Screw
M6*P1*L15
2
123
124
HT003
Cross Round Head Screw
M6*P1*L10
3
