FRYER CM Series - CM-20 Base Assembly Drawing; CM-20 Column & Head Assembly Drawing

55
857
253148
Fixed Bracket
1
858
255121A
Cover Shelf
5MM
1
859
253138D
Plank
5MM
1
860
253148A
Fixed Bracket
1
861
HT003
Cross Round Head Screw
M6*P1*L10
4
863
253122
Crossbar
5MM
1
864
HT003
Cross Round Head Screw
M6*P1*L10
4
865
253149A
Fixed Bracket
1
867
253265C
Plate
1
868
253269
Interval Ring
2
869
HT003
Cross Round Head Screw
M6*P1*L10
2
891
HT003
Cross Round Head Screw
M6*P1*L10
2
894
253293F
Cover
1
895
HT003
Cross Round Head Screw
M6*P1*L10
16
896
253291B
Fixed Bracket
2
897
HT003
Cross Round Head Screw
M6*P1*L10
2
900
253292F
Cover
1
901
HT003
Cross Round Head Screw
M6*P1*L10
12
902
253290D
Guideway
1
903
HT003
Cross Round Head Screw
M6*P1*L10
8
904
HCS39
C-ring
S8
8
905
Bearing
608
8
906
253283A
Guide wheel shaft
8
907
HT003
Cross Round Head Screw
M6*P1*L10
8
908
HT003
Cross Round Head Screw
M6*P1*L10
4
909
253304B
Cover
1380
1
912
253305B
Cover
1380
1
913
253291A
Fixed Bracket
2
932
253345
Way wipers
1
933
HS502
Cross Round Head Screw
M3*P0.5*L5
2
934
253269A
Interval Ring
2
935
253348A
Anti-Dust Board
1
937
HS502
Cross Round Head Screw
M3*P0.5*L5
2
938
253269A
Interval Ring
2
939
253348A
Anti-Dust Board
1
