18
A through F). Each FMU may be configured to use a single PHT. A PHT is needed to complete the
programming interface between an AIM2™ module and the FMU. PHTs are made from operational
nozzle tags which closely match the application in which they are used.
Figure 2-3. Sample Nozzle Tag
Table 2-2. Nozzle Tag Applications
