SECTION 5
AIM2™ PROGRAMMING
Develop an FMU-3500 Programmer
An FMU-3500 Programmer is needed to program the AIM2™ module before it is placed in use, and
may also be used to perform AIM2™ post installation tests. For small quantity installations, the
AIM2™ equipment may be tested and programmed using the FMU-3500 installed at the fuel island.
For larger numbers of installations in a garage or someplace remote from the fuel island, a portable
programmer may be developed and carried to the installation site for testing and programming. A
portable Programmer may be developed by removing the upper cabinet from a fuel island FMU-3500,
or it may be developed from a demonstration unit provided by a FuelMaster® distributor. After testing
and programming is complete, the Programmer may be restored to its original configuration as a fully
configured FMU-3500 or demonstration unit.
A portable Programmer must be configured with the same upper cabinet components as the fuel
island FMU-3500. It must have a compact flash card, an FMU radio board (FRB), antennas, matching
site signature and system type, and a means to receive uploads from the Central Controller.
Configure an FMU-3500 as an FMU-3500 Programmer:
1. Through a laptop connection:
a. Verify the FMU is a master FMU configured as an FMU-3500 with AIM2™ antennas, an
FMU Radio Board, and a compact flash card, and communications with a laptop or Central
Controller has been established.
NOTE
The FuelMaster
®
software may also be loaded on a laptop, and a direct connect cable may be used
to configure an FMU-3500 as an FMU-3500 Programmer in accordance with 3. Through the
Central Controller, below.
b. Establish a laptop connection in accordance with the guidance provided in Product Bulletin
111.
c. At the SITE> prompt, input command 73. The following will be displayed:
AIM2 Configure Programming Unit Status
--------------------------------------
73, ARG1, ARG2
ARG1 – Operation
= 0, Is command supported?
= 1, Is this an AIM programming unit?
= 2, Disable FMU as AIM programming unit.
= 3, Enable FMU as AIM programming unit.
= 4, Set programming hose tag.
= 5, Display current programming hose tag.
ARG2 – Hose Tag Number (use with ARG1 = 4)
d. Input 73,3 and press Enter. The following will be displayed:
FMU programming status set to YES
or
FMU programming status was already YES
