Signal selection
The information items of the inverters that can be monitored are as shown below.
Analog channel signal selection items (Real-time trace / Historical trace)
No Item Note
0 Speed detected value 1 (No polarity)
1 Speed detected value 1 (With polarity)
2
Speed setting 2 (before calculating
acceleration/deceleration)
3 Speed setting 4 (ASR input)
4 Speed detected value 2 (ASR input)
5 Line speed detected value
6
Torque current command
(With polarity)
100%:Motor rated torque current
(P09,A11,A111)
7
Torque current command
(No polarity)
100%:Motor rated torque current
(P09,A11,A111)
8
Torque command
(With polarity)
100%:Rated motor torque (P09,A11,A111)
9
Torque command
(No polarity)
100%:Rated motor torque (P09,A11,A111)
10 Output current
11 Output voltage
12 Inverter input power
13 DC Link voltage
14 Motor temperature
15 Cooling fin temperature
16 Excitation current command
100%:Motor rated excitation current
(P08,A10,A110)
17 Excitation current detected
100%:Motor rated excitation current
(P08,A10,A110)
18 Magnetic-flux command
19 Magnetic-flux calculation
20 Torque calculation
21 Torque current detected
22 U phase current 100%: Motor rated current (P04,A03,A103)
23 V phase current 100%: Motor rated current (P04,A03,A103)
24 W phase current 100%: Motor rated current (P04,A03,A103)
25 U phase voltage 100%: Motor rated voltage (F05,A04,A104)
26 V phase voltage 100%: Motor rated voltage (F05,A04,A104)
27 W phase voltage 100%: Motor rated voltage (F05,A04,A104)
28 Universal AO
29 Option AO
30 Reserve 1 (No polarity) * Do not set.
31 Reserve 1 (With polarity) * Do not set.
32 Reserve 2 (No polarity) * Do not set.
33 Reserve 2 (With polarity) * Do not set.
34 Reserve 3 (No polarity) * Do not set.
35 Reserve 3 (With polarity) * Do not set.
36 Reserve 4 (No polarity) * Do not set.
37 Reserve 4 (With polarity) * Do not set.
38 Output power
39 Magnetic pole position signal
