Stapler Faults
479
Problem Solving
14
Staple Jams in the Staple Cartridge (For Finisher-A1)
The following describes how to clear staple jams in the Finisher-A1 (optional).
1
Make sure that the machine has stopped,
and open the front cover of the finisher.
2
Take the staple cartridge out of the machine.
Note • The staple cartridge is firmly inserted. A
slight force is required to pull the cartridge
out of the finisher.
3
After removing the staple cartridge, check
inside of the finisher for any remaining
staples.
4
Pull up the metal part of the staple cartridge
as shown in the figure.
5
Remove the jammed staples (1), and return
the metal part pulled up in Step 4 to the
original position (2).
CAUTION
Be careful in removing jammed staples.
1
2
To Next Page
