Replacing Consumables
61
Maintenance
3
3
Hold the staple cartridge holder by the
orange lever and remove it from the finisher.
Note • The staple cartridge is firmly inserted. A
slight force is required to pull the cartridge
out of the finisher.
4
Pinch both sides of the empty staple case
with your fingers (1), and remove the staple
case from the cartridge (2).
5
Insert the front side of the new staple case
into the staple cartridge (1), and then push
the rear side into the cartridge (2).
6
Hold the staple cartridge by the orange lever,
and insert it into the finisher until it clicks.
7
Close the front cover of the finisher.
Note • If the front cover of the finisher is not completely closed, a message will appear and the
machine will not operate.
Replacing the Staple Cartridge (for Finisher-C1 or Finisher-C1 with
Booklet Maker)
When the Finisher-C1 (optional) or Finisher-C1 with Booklet Maker (optional) is
installed and it is time to replace the staple cartridge, a message appears on the touch
screen. When this message appears, load a new staple case into the staple cartridge.
This section explains how to replace the staple cartridge in the Finisher-C1 with Booklet
Maker. Use the same procedure for the Finisher-C1.
Important • The use of staple cartridges not recommended by Fuji Xerox may impair quality and
performance. Use only staple cartridges recommended by Fuji Xerox for the machine.
Note • To order a staple cartridge, contact our Customer Support Center.
1
1
2
1
2
To Next Page
