Cleaning the Machine
69
Maintenance
3
2
Turn the top of the drum cartridge release
lever on the front left to the left.
3
Pull the cover towards you.
Note • You can now see the drum cartridge.
4
Slowly pull the cleaning bar housed within
the LED printhead until it stops. The cleaning
bar is stored in the cleaning hole under each
drum cartridge (D1, D2, D3, or D4).
Note • Pull the cleaning bar until the symbol
"zzz" comes out.
Important • Do not draw out the cleaning bar housed
within the machine.
5
Slowly push back the cleaning bar until it
stops.
Note • Clean the four LED printheads by moving
the cleaning bar back and fourth 2 to 3
times respectively.
6
Return the cover to its original position.
Note • Push the cover until it clicks into place.
