Fuji Xerox ApeosPort-VII C7788 - Page 196

7 Problem Solving
196
2 Move handle [1c] to the right (1), turn knob [1e] to the right (2), and remove the jammed
paper (3).
Note
z
The jammed paper may be hidden in the top part.
3 Return handle [1c] to its original position.
4 Close the cover.
 When Lamp E3 is Lit
1 Remove the paper jammed in the output tray.
2
1
3
