Fuji Xerox ApeosPort-VII C7788

7 Problem Solving
218
5 Return handles [3a] and [3b] to their original positions.
6 Close the door.
When the Lamp [E6] is Lit
1 Open the two-sided trimmer front door.
2 Move handle [3a] to the right (1) and handle [4b] downwards (2), move handle [4c] to the
right (3), and remove the jammed paper (4).
3 Turn knob [4d] to the left (1), and remove the jammed paper (2).
1
2
4
3
1
2
