Fuji Xerox ApeosPort-VII C7788 User Manual

3 Paper and Other Media
66
1 Pull out the tray until it stops.
Important
z
While the device is processing a job, do not pull out the tray that the job uses.
z
Do not add a new stack of paper on top of the remaining paper in the tray to prevent paper jams or any other
troubles. First, remove the remaining paper from the tray, and then load the new stack of paper.
2 Remove any paper loaded in the tray.
3 Pinch the paper guide and slide it to the desired paper size.
4 Load and align the edge of the paper against the left edge of the tray, with the side to be
copied or printed on facing down.
Important
z
Do not load paper above the maximum fill line ("MAX" in the figure). It may cause paper jams or device
malfunction.
Note
z
When using punched paper, load the punched paper as shown in the illustration.

Fuji Xerox ApeosPort-VII C7788 Specifications

General

Brand	Fuji Xerox
Model	ApeosPort-VII C7788
Category	All in One Printer
Language	English
