Working with the notebook
18 440 N00072
Indicator drive
The indicator flashes when the hard disk, the floppy disk drive or the CD/DVD
in the optical drive is being accessed.
NumLK indicator (Num Lock)
The key combination [Fn] + [Num LK] has been pressed. The numbers on the
lower left on keys in the integrated numeric keypad are enabled.
CapsLK indicator (Caps Lock)
The Ï key has been pressed. All the characters you type appear in
uppercase. In the case of overlay keys, the character printed on the upper left
of the key appears when that key is pressed.
Keyboard
i
The keyboard of your notebook is subject to continuous wear due to normal use. The
keyboard markings are subjected to particularly high loads. The keyboard markings can
wear off in the course of using the notebook.
The keyboard has been designed to provide all the functions of an enhanced keyboard. Some
enhanced keyboard functions are mapped with key combinations.
The following description of keys refers to Windows. Additional functions supported by the keys are
described in the relevant manuals supplied with your application programmes.
The figure below shows how to access the different characters on keys with overlaid functions. The
example applies when the CapsLK indicator is not lit.
{
7
/
Alt
Gr
7
7
/
{
7
7
/
{
7
7
/
{
7
F11
Num
Fn
(
7
/
{
7
)
Backspace key
The Backspace key deletes the character to the left of the cursor.
Tab key
The Tab key moves the cursor to the next tab stop.
Enter key (return)
The enter key terminates a command line. The command you have entered
is executed when you press this key.
