Technical data
64 440 N00072
Ports
PS/2 port: 6-pin mini DIN female connector
Parallel port: 25-pin female connector, bi-directional, ECP
capable
Monitor port: 15-pin female connector
Serial port: 9-pin male connector, RS232C
Microphone jack: connector, mono
SpDIF headphone/loudspeaker connector: connector, stereo
Video port: 7-pin mini DIN female connector
USB port (Universal Serial Bus): 2.0 twice
LAN connector: Female connector, RJ-45
Modem port: Female connector, RJ-11
IEEE1394 connection: S400, 4-pin
Kensington Lock
Environmental conditions
Environment class 7K1 DIN IEC 721
Environment class 7M2 DIN IEC 721
Temperature:
Operating (7K1)
Transport (2K2)
5 °C .... 35 °C
-15 °C .... 60 °C
Dimensions
Width/depth/height: 326 mm, 275 mm, 40/45 mm
Weight (depending on configuration): approx. 3.6 kg
Battery
Charging time (when not in operation): approx. 3 to 4.5 hours
Operating time approx. 2 hours
Power adapter 90 W
Primary
• Rated voltage: 100 V to 240 V (automatic)
• Frequency: 50 Hz to 60 Hz (automatic)
• Max. rated current: 1,5 A
Secondary
• Rated voltage: 19 V 20 V
• Max. rated current: 4.74 A / 4.5 A
