Technical data
440 N00072 63
for the models AMILO D 6820 / 7820 / 8820
Notebook
Processor: Intel Pentium 4 as from 2,0 GHz
Main memory: Maximum of 2 Gbyte PC 266 DDR So DIMM
2 slots for 128, 256, 512 Mbyte, 1 Gbyte
modules
144 pin JEDEC
Disk drives: Floppy disk drive
Hard disk drive
Optical drive
Electrical data
Regulations complied with: CE, EN60950, Energy Star, SITO
Maximum power draw:
(notebook on with battery charging)
approx. 90 W or 120 W, depending on the model
LCD display panel
Display diagonal: 14.1" XGA TFT
15" XGA TFT
15" SXGA+TFT
Graphics
Chip: ATI M9CSP
Video memory: LCD 14": 32 MB
LCD 15": 64 MB
Supported resolutions on external monitor:
Colour depth:
1600 x 1200
true color
Audio
Sound: 20-bit stereo audio (AC’97)
Input devices
Keyboard: 84/85 keys
Touchpad: 3 keys
Slots
PC Card slots (CardBus/PCMCIA): PCMCIA 2 x Type I or II or 1 x Type III
