MULTI TYPE
2, 3, 4 ROOMS TYPE
MULTI TYPE
2, 3, 4 ROOMS TYPE
INDOOR UNIT CONNECTION PATTERNS
2 Rooms
z
AO
G14LAC2
No. room 1 room 2 total
1 7 7 14
2 7 9 16
3 7 12 19
4 9 9 18
5 9 12 21
AO
G18LAC2
No. room 1 room 2 total
1 7 7 14
2 7 9 16
3 7 12 19
4 7 14 21
5 9 9 18
6 9 12 21
7 9 14 23
8 12 12 24
Notes) 7: 7000Btu/h, 9: 9000Btu/h, 12: 12000Btu/h, 14: 14000Btu/h models
Where "14" means "Wall Mounted type" only models. Other types of indoor units cannot be connected.
3 Rooms
z
AO
G18LAT3
No. room 1 room 2 room 3 total
1 7 7 – 14
2 7 9 – 16
3 7 12 – 19
4 7 14 – 21
5 9 9 – 18
6 9 12 – 21
7 9 14 – 23
8 12 12 – 24
9 12 14 – 26
10 7 7 7 21
11 7 7 9 23
12 7 7 12 26
13 7 7 14 28
14 7 9 9 25
15 7 9 12 28
16 7 9 14 30
17 9 9 9 27
18 9 9 12 30
AO
G24LAT3
No. room 1 room 2 room 3 total
1 7 7 – 14
2 7 9 – 16
3 7 12 – 19
4 7 14 – 21
5 7 18 – 25
6 9 9 – 18
7 9 12 – 21
8 9 14 – 23
9 9 18 – 27
10 12 12 – 24
11 12 14 – 26
12 12 18 – 30
13 7 7 7 21
14 7 7 9 23
15 7 7 12 26
16 7 7 14 28
17 7 7 18 32
18 7 9 9 25
19 7 9 12 28
20 7 9 14 30
21 7 9 18 34
22 7 12 12 31
23 7 12 14 33
24 9 9 9 27
25 9 9 12 30
26 9
9 14 32
27
1
9 9 18 36
28 9 12 12 33
29 9 12 14 35
30 12 12 12 36
Notes) 7: 7000Btu/h, 9: 9000Btu/h, 12: 12000Btu/h, 14: 14000Btu/h, 18: 18000Btu/h models
1: When "AS
G18L" is connected, connect at least 1 wall mounted type of 9000Btu.
To Next Page
