AIR VELOCITY AND TEMPERATURE DISTRIBUTIONS6.
COMPACT CASSETTE TYPE6-1.
MODELS : AU


G07LVLA, AU

G09LVLA
Air velocity distribution
z
Top view
Vertical airow direction louver: Up
2.0
2.0
2.0
2.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.25
0.25
0.25
0.25
Unit : m/s
(m)
0
1
1
2
2
3
3
4
4
(m)
0 11 22 33 44
Side view
Vertical airow direction louver: Up
2.0
1.0
0.5 0.5
0.25 0.25
Unit : m/s
(m)
0
1
2
2.7
(m)
0 11 22 33 44
Conditions
Fan speed: HIGH
Operation mode: FAN
