Fujitsu AO*G24LAT3 User Manual

- (04 - 74) -
OUTDOOR UNIT AO

G30L4
OUTDOOR UNIT AO

G30L4
ELECTRIC CHARACTERISTICS10.
Model name AO

G30L4
Power supply
Voltage V 230 ~
Frequency Hz 50
Max. operating current A 15.7
Starting current A 10.5
*1) Wiring spec.
Main fuse (Circuit breaker)
current
A 25
Power cable mm
2
4.0
*2) Limited wiring length m 15
*1) Wiring spec.
Selected sample
(Selected based on Japan Electrotechnical Standard and Codes Committee E0005)
*2) Limited wiring length :
This is the wiring length in case voltage descent is less than 2%.
When the wiring length becomes long, please select the wiring of a more larger diameter.
