Fujitsu AO*G24LAT3 User Manual

- (02 - 32) -
OUTDOOR UNIT AO

G14-18L2
OUTDOOR UNIT AO

G14-18L2
ELECTRIC CHARACTERISTICS10.
Model name AO
Û
G14L2 AO
Û
G18L2
Power supply
Voltage V 230 ~
Frequency Hz 50
Max. operating current A 10 12
Starting current A 4.9 6.3
*1) Wiring spec.
Main fuse (Circuit breaker)
current
A 15
Power cable mm
2
2.5
*2) Limited wiring length m 16
*1) Wiring spec.
Selected sample
(Selected based on Japan Electrotechnical Standard and Codes Committee E0005)
*2) Limited wiring length :
This is the wiring length in case voltage descent is less than 2%.
When the wiring length becomes long, please select the wiring of a more larger diameter.
