- (04 - 75) -
OUTDOOR UNIT
AO
G30L4
OUTDOOR UNIT
AO
G30L4
SAFETY DEVICES11.
Protection form
Model
AO
G30L4
Circuit protection
Current fuse (MAIN PCB)
5A 250V
3.15A 250V
Current fuse
(NEAR THE TERMINAL TO
POWER SUPPLY)
25A 250V
Current fuse
(NEAR THE TERMINAL TO
INDOOR UNIT)
15A 250V
Fan motor protection Thermal protector
OFF :130±20°C
ON : 100±20°C
Compressor protection Thermal protector
OFF : 125°C
ON : 80°C
High pressure protection Pressure switch (1)
OFF :4.2±0.10MPa
ON : 3.2±0.15MPa
Pressure switch (2) : For control device
