- (01-15) -
MULTI TYPE
2, 3, 4 ROOMS TYPE
MULTI TYPE
2, 3, 4 ROOMS TYPE
SYSTEM DIAGRAM
Signal transmitter
Signal receiver
window
Control signal might not be recognized in following cases: ●
(i) A curtain or a wall, etc. exists between transmitter and receiver.
(ii) There is an instant-start type (inverter type, etc.) uorescent lamp
in the room.
Air conditioner might not work correctly when strong light hits the ●
signal receiver window. Shut off the direct sunlight and also make
illuminator far away from the receiver window.
DIMENSIONS
Controller
z
To Next Page
