- (03 - 06) -
OUTDOOR UNIT
AO
G18-24L3
OUTDOOR UNIT
AO
G18-24L3
CAPACITY TABLE5.
COMBINATIONS5-1.
MODEL
: AO
G18L3
Cooling
z
Combination
of indoor unit
COOLING OPERATION
Cooling Capacity
Input Power
(min-max)
EER
Seasonal Data
Room 1 Room 2 Room 3
Total Capacity
(min-max)
Pdesign
SEER
Energy
Efciency
Class
KW KW KW KW KW kW
2 Room
7 7 - 2.30 2.30 - 4.60 ( 1.8 - 5.0 ) 1.22 ( 0.50 - 1.43 ) 3.77 4.6 6.3 A++
7 9 - 2.30 2.70 - 5.00 ( 1.8 - 5.7 ) 1.35 ( 0.50 - 1.81 ) 3.70 5.0 6.2 A++
7 12 - 1.98 3.02 - 5.00 ( 1.8 - 6.1 ) 1.34 ( 0.50 - 2.06 ) 3.73 5.0 6.2 A++
7 14 - 1.88 3.42 - 5.30 ( 1.8 - 6.6 ) 1.34 ( 0.50 - 2.06 ) 3.96 5.3 6.1 A++
9 9 - 2.50 2.50 - 5.00 ( 1.8 - 6.2 ) 1.35 ( 0.50 - 2.06 ) 3.70 5.0 6.2 A++
9 12 - 2.18 2.82 - 5.00 ( 1.8 - 6.3 ) 1.35 ( 0.50 - 2.06 ) 3.70 5.0 6.2 A++
9 14 - 2.07 3.23 - 5.30 ( 1.8 - 6.7 ) 1.35 ( 0.50 - 2.06 ) 3.93 5.3 6.1 A++
12 12 - 2.55 2.55 - 5.10 ( 1.8 - 6.3 ) 1.35 ( 0.50 - 2.06 ) 3.78 5.1 6.1 A++
12 14 - 2.41 2.89 - 5.30 ( 1.8 - 6.7 ) 1.35 ( 0.50 - 2.06 ) 3.93 5.3 6.1 A++
3 Room
7 7 7 1.80 1.80 1.80 5.40 ( 1.8 - 6.8 ) 1.35 ( 0.50 - 2.06 ) 4.00 5.4 6.9 A++
7 7 9 1.70 1.70 2.00 5.40 ( 1.8 - 6.8 ) 1.35 ( 0.50 - 2.06 ) 4.00 5.4 6.9 A++
7 7 12 1.53 1.53 2.33 5.40 ( 1.8 - 6.8 ) 1.35 ( 0.50 - 2.06 ) 4.00 5.4 6.7 A++
7 7 14 1.41 1.41 2.58 5.40 ( 2.0 - 6.8 ) 1.35 ( 0.60 - 2.06 ) 4.00 5.4 6.7 A++
7 9 9 1.61 1.89 1.89 5.40 ( 1.8 - 6.8 ) 1.35 ( 0.50 - 2.06 ) 4.00 5.4 6.8 A++
7 9 12 1.46 1.72 2.22 5.40 ( 1.8 - 6.8 ) 1.35 ( 0.50 - 2.06 ) 4.00 5.4 6.7 A++
7 9 14 1.35 1.58 2.47 5.40 ( 2.0 - 6.8 ) 1.35 ( 0.60 - 2.06 ) 4.00 5.4 6.7 A++
9 9 9 1.80 1.80 1.80 5.40 ( 1.8 - 6.8 ) 1.35 ( 0.50 - 2.06 ) 4.00 5.4 6.8 A++
9 9 12 1.64 1.64 2.12 5.40 ( 1.8 - 6.8 ) 1.35 ( 0.50 - 2.06 ) 4.00 5.4 6.7 A++
Heating
z
Combination
of indoor unit
HEATING OPERATION
Heating Capacity
Input Power
(min-max)
COP
Seasonal Data
Room 1 Room 2 Room 3
Total Capacity
(min-max)
Pdesign
SCOP
Energy
Efciency
Class
KW KW KW KW KW kW
2 Room
7 7 - 2.70 2.70 - 5.40 ( 2.0 - 6.1 ) 1.59 ( 0.52 - 1.93 ) 3.40 4.0 4.1 A+
7 9 - 2.75 3.25 - 6.00 ( 2.0 - 6.4 ) 1.87 ( 0.52 - 2.06 ) 3.21 4.0 4.1 A+
7 12 - 2.59 3.71 - 6.30 ( 2.0 - 6.5 ) 1.98 ( 0.52 - 2.06 ) 3.18 4.0 4.1 A+
7 14 - 2.51 4.29 - 6.80 ( 2.0 - 7.1 ) 1.92 ( 0.50 - 2.06 ) 3.54 4.0 4.1 A+
9 9 - 3.15 3.15 - 6.30 ( 2.0 - 6.5 ) 1.98 ( 0.52 - 2.06 ) 3.18 4.0 4.1 A+
9 12 - 2.89 3.51 - 6.40 ( 2.0 - 6.6 ) 1.99 ( 0.52 - 2.06 ) 3.22 4.0 4.1 A+
9 14 - 2.77 4.03 - 6.80 ( 2.0 - 7.2 ) 1.91 ( 0.50 - 2.06 ) 3.56 4.0 4.1 A+
12 12 - 3.20 3.20 - 6.40 ( 2.0 - 6.6 ) 1.98 ( 0.52 - 2.06 ) 3.23 4.0 4.1 A+
12 14 - 3.09 3.71 - 6.80 ( 2.0 - 7.3 ) 1.90 ( 0.50 - 2.06 ) 3.58 4.0 4.1 A+
3 Room
7 7 7 2.27 2.27 2.27 6.80 ( 2.0 - 7.7 ) 1.62 ( 0.50 - 2.06 ) 4.20 5.0 4.3 A+
7 7 9 2.14 2.14 2.52 6.80 ( 2.0 - 7.8 ) 1.62 ( 0.50 - 2.06 ) 4.20 5.0 4.3 A+
7 7 12 1.98 1.98 2.83 6.80 ( 2.0 - 7.8 ) 1.59 ( 0.50 - 2.06 ) 4.28 5.0 4.3 A+
7 7 14 1.83 1.83 3.14 6.80 ( 2.0 - 8.0 ) 1.61 ( 0.50 - 2.06 ) 4.22 5.0 4.3 A+
7 9 9 2.03 2.39 2.39 6.80 ( 2.0 - 7.8 ) 1.60 ( 0.50 - 2.06 ) 4.25 5.0 4.3 A+
7 9 12 1.89 2.22 2.69 6.80 ( 2.0 - 7.9 ) 1.59 ( 0.50 - 2.06 ) 4.28 5.0 4.3 A+
7 9 14 1.75 2.06 2.99 6.80 ( 2.0 - 8.0 ) 1.60 ( 0.50 - 2.06 ) 4.25 5.0 4.3 A+
9 9 9 2.27 2.27 2.27 6.80 ( 2.0 - 7.9 ) 1.59 ( 0.50 - 2.06 ) 4.28 5.0 4.3 A+
9 9 12 2.12 2.12 2.57 6.80 ( 2.0 - 7.9 ) 1.59 ( 0.50 - 2.06 ) 4.28 5.0 4.3 A+
Notes:
7: 7000Btu/h, 9: 9000Btu/h, 12: 12000Btu/h ,14:14000Btu/h models.
•
The above is the value for connecting with Wall Mounted type.
•
2 or more indoor units should be connected.
•
Cooling capacity is based on 27 °CDB / 19 °CWB (indoor temperature), 35 °CDB (outdoor temperature).
•
Heating capacity is based on 20 °CDB (indoor temperature), 7 °CDB / 6 °CWB (outdoor temperature).
•
Pipe length : 5m, Height difference : 0m. (Outdoor unit to indoor unit)
•
The total ability of connected a indoor unit is up to 30000 Btu from 14000 Btu.
•
