SLIM DUCT TYPE3-2.
Model name AR
G07LLTA AR
G09LLTA
AR
G12LLTA
AR
G12LLTB
AR
G14LLTA
AR
G14LLTB
AR
G18LLTA
AR
G18LLTB
Power source 1ø 230V ~ 50Hz
Available voltage range 198-264V
Capacity 2.0kW Class 2.5kW Class 3.5kW Class 4.0kW Class 5.0kW Class
Input power W 33 49 58 76 73
Running current A 0.33 0.30 0.35 0.51 0.44
Fan
Airow
rate
Cooling
High
m
3
/h
550 600 650 800 940
Med 490 550 600 700 880
Low 470 500 550 600 820
Quiet 440 450 480 480 750
Heating
High 550 600 650 800 940
Med 490 550 600 700 880
Low 470 500 550 600 820
Quiet 440 450 480 480 750
Type × Q'ty Sirocco × 2 Sirocco × 3
Motor output W 80 81 96
Recommended static pressure Pa 0 to 90
Sound pressure level *
Cooling
High
dB(A)
28 28 29
32
32
Med 26 27 28
30
31
Low 25 26
27
28
30
Quiet 24 25 26
26
29
Heating
High 28 28 29
33
33
Med 26 26 28
30
32
Low 25 25 27
28
31
Quiet 24 24 24
25
29
Sound power level
Cooling 57 57 58 60 58
Heating 57 57 58 61 59
Heat
exchanger
Dimension (H × W × D)
mm
294 × 500 × 26.6 294 × 500 × 39.9 294 × 700 × 39.9
Fin pitch 1.3
Rows × Stages 2 × 14 3 × 14
Pipe type Copper tube
Fin Type Aluminium
Enclosure
Material GALVANIZED STEEL SHEET
Colour -
Dimensions
(H × W × D)
Net
mm
198 × 700 × 620 198 × 900 × 620
Gross 276 × 968 × 772 276 × 1168 ×772
Weight
Net
kg
17 19 23
Gross 24 26 30
Connection
pipe
Size
Liquid
mm
Ø6.35 (Ø1/4in.)
Gas Ø9.52 (Ø3/8in.) Ø12.7 (Ø1/2in.)
Method Flare
Drain hose
Material HARD PVC
size mm Φ25 (I.D.), Φ32 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wired [Wireless (option)]
NOTE:
Specications are based on the following conditions.
Static Pressure : 25Pa
The protective function may work when using it outside the operation range.
*: These are the measured values in the manufacturers anechoic chamber.
Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than
the specied values here.
