- (03 - 44) -
OUTDOOR UNIT
AO
G18-24L3
OUTDOOR UNIT
AO
G18-24L3
ADDITIONAL CHARGE CALCULATION7.
MODEL
: AO
G18L3, AO
G24L3
Refrigerant charge
z
Refrigerant type R410A
Refrigerant amount g 2200
Total pipe length m 30 or less 40 50 (MAX.)
20g/m
Additional charge g 0 200 400
