- (01-63) -
MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
FLOOR / CEILING TYPE 4-4.
MODELS : AB


G14LVTA, AB

G18LVTA,
AB

G18LVTB
1
2
3
45
6
3
1 2
Side view
Rear view
Bottom view
(Drain hose)
100 hole
50 hole
125
100 hole
655
530
45
65
500 245
990
65
Wall bracket
Side of set
AB

G14L, AB

G18L

Refrigerant pipe are
connection
Liquid ø 6.35 mm (ø 1/4 in.)

Gas ø 12.70 mm (ø 1/2 in.)

Drain hose connection Drain hose O.D. 32 mm (VP25)

Knock out hole
Drain outlet ø 45 mm

- -

Hole for suspension bolt - Use M10 bolt
