Fujitsu AO*G24LAT3 User Manual

- (02 - 01) -
OUTDOOR UNIT AO

G14-18L2
OUTDOOR UNIT AO

G14-18L2
SPECIFICATIONS1.
The following performance is a value at standard combinations.
STANDARD COMBINATION

AO

G14LAC2 : AS

G07LMCA + AS

G07LMCA
AO

G18LAC2 : AS

G09LMCA + AS

G09LMCA
Type
INVERTER MULTI MODELS
HEAT PUMP TYPE
Model name AO

G14LAC2 AO

G18LAC2
Power source 230V ~ 50Hz
Available voltage range 198-264V ~ 50Hz
Capacity
Cooling
Rated
kW 4.0 5.0
Btu/h 13600 17100
Min. - Max.
kW 1.4 - 4.4 1.7 - 5.6
Btu/h 4700 - 15000 5800 - 19100
Heating
Rated
kW 4.4 5.6
Btu/h 15000 19100
Min. - Max.
kW 1.1 - 5.4 1.8 - 6.1
Btu/h 3700 - 18400 6100 - 20800
Input power
Cooling
Rated
kW
1.09 1.56
Max. 1.40 1.95
Heating
Rated 1.03 1.41
Max. 1.78 1.90
Current
Cooling
Rated A
5.1 6.9
Heating 4.9 6.3
EER Cooling
Rated kW/kW
3.67 3.21
COP Heating 4.27 3.97
Starting current A 5.1 6.9
Maximum operating current A 10.0 12.0
Fan
Airow rate
Cooling
m
3
/h
1850 2050
Heating 1850 2050
Type x Q'ty Propeller × 1
Motor output W 50
Sound pressure level *1
Cooling
dB(A)
47 50
Heating 49 51
Heat
exchanger
type
Dimension (H × W × D)
mm
504 × 850 × 36.4
Fin pitch 1.4
Rows x Stages 2 × 24
Pipe type Copper tube
Fin type Aluminium
Compressor
Type x Q'ty DC ROTARY × 1 DC TWIN ROTARY × 1
Motor output W 750
900
Refrigerant
Type (Global Warming Potential) R410A (1975)
Charge g 1250 1300
Refrigerant oil Type POE
Enclosure
Material Steel sheet
Colour
BEIGE
(Approximate colour of MUNSELL 10YR7.5 / 1.0NN)
Dimensions
(H × W × D)
Net
mm
540 × 790 × 290
Gross 648 × 910 × 380
Weight
Net
kg
37 38
Gross 41 42
Connection pipe
Size
Liquid
mm
Ø6.35 (Ø1/4 in.) × 2
Gas Ø9.52 (Ø3/8 in.) × 2
Ø9.52 (Ø3/8in.) × 2,
[Ø12.70 (Ø1/2in.)]

2
Method Flare
Pre-charge length (Total)
m
20
Max. length (Total) 30
Max. length (Each) 20
Min. length (Total) 6
Min. length (Each) 3
Max. height difference between
Outdoor Unit and each Indoor Units.
15
Max. height difference between
Indoor Units.
10
Operation range
Cooling
°C
10 to 46
Heating -15 to 24
NOTE:
Specications are based on the following conditions.
Cooling: Indoor temperature of 27 °CDB / 19 °CWB.and outdoor temperature of 35 °CDB / 24 °CWB.
Heating: Indoor temperature of 20 °CDB / 15 °CWB.and outdoor temperature of 7 °CDB / 6 °CWB.
Pipe length: 5m, Height difference: 0m. (Outdoor unit - indoor unit)
The protective function might work when using it outside the operation range.
*1: These are the measured values in the manufacturer’s anechoic chamber.
Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specied
values here.
*2: Connect to connection valve by the adapter
