Fujitsu AO*G24LAT3 User Manual

- (01-43) -
MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
WALL MOUNTED TYPE3-3.
Model name AS

G07LJCA AS

G09LJCA AS

G12LJCA
Power source 1ø 230V ~ 50Hz
Available voltage range 198-264V
Capacity 2.0kW Class 2.5kW Class 3.5kW Class
Input power W 15 17 22
Running current A 0.13 0.15 0.19
Fan
Airow
rate
Cooling
High
m
3
/h
560 600 660
Med 500 520 560
Low 430 430 450
Quiet 310 310 310
Heating
High 560 600 660
Med 500 520 560
Low 430 430 470
Quiet 330 330 330
Type × Q'ty Crossow ×1
Motor output W 30
Sound pressure level *
Cooling
High
dB(A)
36 37 40
Med 32 33 36
Low 29 29 30
Quiet 21 21 21
Heating
High 36 37 40
Med 32 33 36
Low 29 29 31
Quiet 22 22 22
Sound power level
Cooling 51 52 54
Heating 51 52 54
Heat
exchanger
Dimension (H × W × D)
mm
Main: 320 x 630 x 20
Sub: 84 x 630 x 13.3
Fin pitch Main: 1.1, Sub:1.4
Rows × Stages Main: 2 x 20, Sub:1 x 4
Pipe type Copper tube
Fin Type Aluminium
Enclosure
Material Polystyrene
Colour
WHITE
(Approximate colour of MUNSELL N9.25)
Dimensions
(H × W × D)
Net
mm
280 × 790 × 203
Gross 263 × 840 × 375
Weight
Net
kg
8
Gross 10.5
Connection
pipe
Size
Liquid
mm
Ø6.35 (Ø1/4in.)
Gas Ø9.52 (Ø3/8in.)
Method Flare
Drain hose
Material PP+LLDPE
size mm Φ13.8 (I.D.), Φ15.8 to 16.7 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless [Wired (option)]
NOTE:
The protective function may work when using it outside the operation range.
*: These are the measured values in the manufacturer’s anechoic chamber.
Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than
the specied values here.
