Fujitsu AO*G24LAT3 User Manual

- (04 - 06) -
OUTDOOR UNIT AO

G30L4
OUTDOOR UNIT AO

G30L4
CAPACITY TABLE5.
COMBINATIONS5-1.
MODEL

: AO

G30L4
Cooling
z
Combination
of indoor unit
COOLING OPERATION
Cooling Capacity
Input Power
(min-max)
EER
Seasonal Data
Room 1 Room 2 Room 3 Room 4
Total Capacity
(min-max)
Pdesign
SEER
Energy
Efciency
Class
KW KW KW KW KW KW kW
3 Room
7 7 14 - 1.96 1.96 3.27 - 7.20 ( 1.6 - 8.9 ) 2.22 ( 0.68 - 3.43 ) 3.24 7.2 5.9 A+
7 7 18 - 1.81 1.81 4.08 - 7.70 ( 2.8 - 10.0 ) 2.22 ( 0.98 - 3.55 ) 3.47 7.7 5.8 A+
7 7 24 - 1.61 1.61 4.57 - 7.80 ( 2.8 - 10.1 ) 2.19 ( 0.98 - 3.53 ) 3.56 7.8 5.8 A+
7 9 12 - 2.08 2.34 2.78 - 7.20 ( 1.6 - 8.9 ) 2.22 ( 0.68 - 3.41 ) 3.24 7.2 5.9 A+
7 9 14 - 1.90 2.14 3.16 - 7.20 ( 2.8 - 9.1 ) 2.22 ( 0.98 - 3.56 ) 3.24 7.2 5.9 A+
7 9 18 - 1.76 1.98 3.96 - 7.70 ( 2.8 - 9.9 ) 2.22 ( 0.98 - 3.56 ) 3.47 7.7 5.8 A+
7 9 24 - 1.57 1.77 4.46 - 7.80 ( 2.8 - 10.1 ) 2.19 ( 0.98 - 3.53 ) 3.56 7.8 5.8 A+
7 12 12 - 1.96 2.62 2.62 - 7.20 ( 1.6 - 9.1 ) 2.22 ( 0.68 - 3.54 ) 3.24 7.2 5.9 A+
7 12 14 - 1.83 2.43 3.04 - 7.30 ( 2.8 - 9.2 ) 2.22 ( 0.98 - 3.56 ) 3.29 7.3 5.9 A+
7 12 18 - 1.68 2.24 3.78 - 7.70 ( 2.8 - 9.9 ) 2.22 ( 0.98 - 3.56 ) 3.47 7.7 5.8 A+
7 12 24 - 1.51 2.01 4.28 - 7.80 ( 2.8 - 10.1 ) 2.19 ( 0.98 - 3.56 ) 3.56 7.8 5.8 A+
7 14 14 - 1.68 2.81 2.81 - 7.30 ( 2.8 - 9.3 ) 2.22 ( 0.98 - 3.58 ) 3.29 7.3 5.9 A+
7 14 18 - 1.57 2.61 3.52 - 7.70 ( 3.5 - 10.0 ) 2.22 ( 1.17 - 3.58 ) 3.47 7.7 5.8 A+
7 14 24 - 1.44 2.39 4.07 - 7.90 ( 3.5 - 10.1 ) 2.20 ( 1.17 - 3.58 ) 3.59 7.9 5.8 A+
7 18 18 - 1.42 3.19 3.19 - 7.80 ( 3.5 - 10.1 ) 2.22 ( 1.17 - 3.58 ) 3.51 7.8 5.7 A+
7 18 24 - 1.30 2.92 3.68 - 7.90 ( 4.7 - 10.1 ) 2.22 ( 1.27 - 3.58 ) 3.56 7.9 5.7 A+
9 9 9 - 2.40 2.40 2.40 - 7.20 ( 2.8 - 8.9 ) 2.22 ( 0.98 - 3.42 ) 3.24 7.2 5.9 A+
9 9 12 - 2.26 2.26 2.68 - 7.20 ( 2.8 - 9.1 ) 2.22 ( 0.98 - 3.54 ) 3.24 7.2 5.9 A+
9 9 14 - 2.10 2.10 3.11 - 7.30 ( 2.8 - 9.2 ) 2.22 ( 0.98 - 3.57 ) 3.29 7.3 5.9 A+
9 9 18 - 1.93 1.93 3.85 - 7.70 ( 2.8 - 9.9 ) 2.22 ( 0.98 - 3.56 ) 3.47 7.7 5.8 A+
9 9 24 - 1.73 1.73 4.35 - 7.80 ( 2.8 - 10.1 ) 2.20 ( 1.17 - 3.54 ) 3.55 7.8 5.8 A+
9 12 12 - 2.14 2.53 2.53 - 7.20 ( 2.8 - 9.1 ) 2.22 ( 0.98 - 3.54 ) 3.24 7.2 5.9 A+
9 12 14 - 1.99 2.36 2.95 - 7.30 ( 2.8 - 9.2 ) 2.22 ( 0.98 - 3.57 ) 3.29 7.3 5.9 A+
9 12 18 - 1.84 2.18 3.68 - 7.70 ( 2.8 - 9.9 ) 2.22 ( 0.98 - 3.56 ) 3.47 7.7 5.8 A+
9 12 24 - 1.66 1.97 4.18 - 7.80 ( 2.8 - 10.1 ) 2.19 ( 0.98 - 3.56 ) 3.56 7.8 5.8 A+
9 14 14 - 1.84 2.73 2.73 - 7.30 ( 3.5 - 9.3 ) 2.22 ( 1.17 - 3.58 ) 3.29 7.3 5.9 A+
9 14 18 - 1.74 2.58 3.48 - 7.80 ( 3.5 - 10.0 ) 2.22 ( 1.17 - 3.58 ) 3.51 7.8 5.8 A+
9 14 24 - 1.58 2.34 3.98 - 7.90 ( 3.5 - 10.1 ) 2.22 ( 1.27 - 3.56 ) 3.56 7.9 5.8 A+
9 18 18 - 1.56 3.12 3.12 - 7.80 ( 4.7 - 10.1 ) 2.22 ( 1.27 - 3.58 ) 3.51 7.8 5.7 A+
12 12 12 - 2.43 2.43 2.43 - 7.30 ( 2.8 - 9.2 ) 2.22 ( 0.98 - 3.55 ) 3.29 7.3 5.9 A+
12 12 14 - 2.28 2.28 2.85 - 7.40 ( 2.8 - 9.3 ) 2.22 ( 0.98 - 3.58 ) 3.33 7.4 5.9 A+
12 12 18 - 2.12 2.12 3.57 - 7.80 ( 3.5 - 10.0 ) 2.22 ( 1.17 - 3.57 ) 3.51 7.8 5.8 A+
12 12 24 - 1.92 1.92 4.07 - 7.90 ( 3.5 - 10.1 ) 2.20 ( 1.17 - 3.54 ) 3.59 7.9 5.8 A+
12 14 14 - 2.11 2.64 2.64 - 7.40 ( 3.5 - 9.4 ) 2.22 ( 1.17 - 3.58 ) 3.33 7.4 5.9 A+
12 14 18 - 1.98 2.48 3.34 - 7.80 ( 3.5 - 10.1 ) 2.22 ( 1.17 - 3.58 ) 3.51 7.8 5.8 A+
12 18 18 - 1.81 3.05 3.05 - 7.90 ( 4.7 - 10.1 ) 2.22 ( 1.27 - 3.58 ) 3.56 7.9 5.7 A+
Notes:
7:7000Btu/h, 9:9000Btu/h, 12:12000Btu/h, 14:14000Btu/h, 18:18000Btu/h, 24:24000Btu/h models. •
The above is the value for connecting with Wall Mounted type. •
3 or more indoor units should be connected. •
Cooling capacity is based on 27 °CDB /19 °CWB (indoor temperature),35 °CDB (outdoor temperature). •
Pipe l • ength : 5m, Height difference : 0m. (Outdoor unit to indoor unit)
The total ability of connected a indoor unit is up to 49000 Btu from 27000 Btu. •
