Fujitsu AO*G24LAT3 User Manual

- (04 - 07) -
OUTDOOR UNIT AO

G30L4
OUTDOOR UNIT AO

G30L4
Combination
of indoor unit
COOLING OPERATION
Cooling Capacity
Input Power
(min-max)
EER
Seasonal Data
Room 1 Room 2 Room 3 Room 4
Total Capacity
(min-max)
Pdesign
SEER
Energy
Efciency
Class
KW KW KW KW KW KW kW
4 Room
7 7 7 7 1.93 1.93 1.93 1.93 7.70 ( 1.6 - 9.6 ) 2.20 ( 0.68 - 3.41 ) 3.50 7.7 6.2 A++
7 7 7 9 1.89 1.89 1.89 2.13 7.80 ( 1.6 - 9.8 ) 2.22 ( 0.68 - 3.54 ) 3.51 7.8 6.2 A++
7 7 7 12 1.83 1.83 1.83 2.41 7.90 ( 1.6 - 9.9 ) 2.22 ( 0.68 - 3.54 ) 3.56 7.9 6.1 A++
7 7 7 14 1.70 1.70 1.70 2.80 7.90 ( 2.8 - 9.9 ) 2.22 ( 0.98 - 3.56 ) 3.56 7.9 6.1 A++
7 7 7 18 1.52 1.52 1.52 3.43 8.00 ( 2.8 - 10.1 ) 2.20 ( 0.98 - 3.55 ) 3.64 8.0 6.0 A+
7 7 9 9 1.86 1.86 2.09 2.09 7.90 ( 2.8 - 9.7 ) 2.22 ( 0.98 - 3.42 ) 3.56 7.9 6.2 A++
7 7 9 12 1.78 1.78 1.99 2.35 7.90 ( 2.8 - 9.9 ) 2.22 ( 0.98 - 3.55 ) 3.56 7.9 6.1 A++
7 7 9 14 1.68 1.68 1.88 2.76 8.00 ( 2.8 - 10.0 ) 2.22 ( 0.98 - 3.57 ) 3.60 8.0 6.1 A++
7 7 9 18 1.49 1.49 1.67 3.35 8.00 ( 3.5 - 10.1 ) 2.20 ( 1.17 - 3.55 ) 3.64 8.0 6.0 A+
7 7 12 12 1.72 1.72 2.28 2.28 8.00 ( 2.8 - 10.0 ) 2.22 ( 0.98 - 3.55 ) 3.60 8.0 6.1 A++
7 7 12 14 1.61 1.61 2.13 2.65 8.00 ( 2.8 - 10.0 ) 2.22 ( 0.98 - 3.57 ) 3.60 8.0 6.1 A++
7 7 12 18 1.43 1.43 1.91 3.22 8.00 ( 3.5 - 10.1 ) 2.20 ( 1.17 - 3.56 ) 3.64 8.0 6.0 A+
7 7 14 14 1.50 1.50 2.50 2.50 8.00 ( 3.5 - 10.1 ) 2.22 ( 1.17 - 3.58 ) 3.60 8.0 6.0 A+
7 7 14 18 1.35 1.35 2.25 3.04 8.00 ( 3.5 - 10.1 ) 2.22 ( 1.17 - 3.58 ) 3.60 8.0 6.0 A+
7 9 9 9 1.81 2.03 2.03 2.03 7.90 ( 2.8 - 9.9 ) 2.22 ( 0.98 - 3.56 ) 3.56 7.9 6.2 A++
7 9 9 12 1.76 1.96 1.96 2.32 8.00 ( 2.8 - 10.0 ) 2.22 ( 0.98 - 3.56 ) 3.60 8.0 6.1 A++
7 9 9 14 1.64 1.83 1.83 2.70 8.00 ( 3.5 - 10.1 ) 2.22 ( 1.17 - 3.58 ) 3.60 8.0 6.1 A++
7 9 9 18 1.45 1.64 1.64 3.27 8.00 ( 3.5 - 10.1 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
7 9 12 12 1.68 1.88 2.22 2.22 8.00 ( 2.8 - 10.0 ) 2.22 ( 0.98 - 3.56 ) 3.60 8.0 6.1 A++
7 9 12 14 1.57 1.76 2.08 2.59 8.00 ( 3.5 - 10.1 ) 2.22 ( 1.17 - 3.58 ) 3.60 8.0 6.0 A+
7 9 12 18 1.40 1.58 1.87 3.15 8.00 ( 3.5 - 10.1 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
7 9 14 14 1.48 1.66 2.43 2.43 8.00 ( 3.5 - 10.1 ) 2.22 ( 1.17 - 3.58 ) 3.60 8.0 6.0 A+
7 9 14 18 1.32 1.49 2.21 2.98 8.00 ( 4.7 - 10.1 ) 2.22 ( 1.27 - 3.57 ) 3.60 8.0 6.0 A+
7 12 12 12 1.61 2.13 2.13 2.13 8.00 ( 2.8 - 10.1 ) 2.22 ( 0.98 - 3.56 ) 3.60 8.0 6.0 A+
7 12 12 14 1.51 2.00 2.00 2.49 8.00 ( 3.5 - 10.1 ) 2.22 ( 1.17 - 3.58 ) 3.60 8.0 6.0 A+
7 12 12 18 1.35 1.80 1.80 3.04 8.00 ( 3.5 - 10.1 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
7 12 14 14 1.41 1.89 2.35 2.35 8.00 ( 3.5 - 10.1 ) 2.22 ( 1.17 - 3.58 ) 3.60 8.0 6.0 A+
9 9 9 9 2.00 2.00 2.00 2.00 8.00 ( 3.5 - 10.0 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.2 A++
9 9 9 12 1.91 1.91 1.91 2.27 8.00 ( 3.5 - 10.0 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.1 A++
9 9 9 14 1.79 1.79 1.79 2.63 8.00 ( 3.5 - 10.0 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
9 9 9 18*1 1.60 1.60 1.60 3.20 8.00 ( 4.7 - 10.0 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
9 9 12 12 1.83 1.83 2.17 2.17 8.00 ( 3.5 - 10.0 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
9 9 12 14 1.72 1.72 2.03 2.53 8.00 ( 3.5 - 10.0 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
9 9 12 18*2 1.54 1.54 1.83 3.09 8.00 ( 4.7 - 10.0 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
9 9 14 14 1.62 1.62 2.38 2.38 8.00 ( 4.7 - 10.0 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
9 12 12 12 1.76 2.08 2.08 2.08 8.00 ( 3.5 - 10.0 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
9 12 12 14 1.66 1.95 1.95 2.44 8.00 ( 3.5 - 10.0 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
9 12 14 14 1.55 1.85 2.30 2.30 8.00 ( 4.7 - 10.0 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
12 12 12 12 2.00 2.00 2.00 2.00 8.00 ( 3.5 - 10.0 ) 2.22 ( 1.17 - 3.56 ) 3.60 8.0 6.0 A+
Notes:
7:7000Btu/h, 9:9000Btu/h, 12:12000Btu/h, 14:14000Btu/h, 18:18000Btu/h, 24:24000Btu/h models. •
The above is the value for connecting with Wall Mounted type. •
3 or more indoor units should be connected. •
Cooling capacity is based on 27 °CDB /19 °CWB (indoor temperature),35 °CDB (outdoor temperature). •
Pipe l • ength : 5m, Height difference : 0m. (Outdoor unit to indoor unit)
The total ability of connected a indoor unit is up to 49000 Btu from 27000 Btu. •

1: Connection of "AR

G09L+AR

G09L+AR

G09L+AS

G18L " is not available. All types other than this combination can be connected.

2: Connection of "AR

G09L+AR

G09L+AR

G12 L+A S

G18L " is not available. All types other than this combination can be connected.

Fujitsu AO*G24LAT3 Specifications

General

Brand	Fujitsu
Model	AO*G24LAT3
Category	Air Conditioner
Language	English
