MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
INSTALLATION PLACE

1000
or more
1000
or more
1800
or more
262
or more
Strong and durable ceiling
Obstruction
Floor
H
H (The maximum height from oor to ceiling) Unit: mm
Model name AU

G07 AU

G09 AU

G12 AU

G14 AU

G18
Standard mode 2700 2700 2700 2700 2700
High Ceiling mode - - 3000 3000 3000
3-way directions setting
z
100 or more
*
To set “3-way directions”, the air outlet shutter plate (UTR-YDZB) sold separately must be
installed and “outlet-direction” switched to “3-way” by remote controller.
*When installing the indoor unit, be careful about the maintenance space.
Unit : mm
