MULTI TYPE
2, 3, 4 ROOMS TYPE
MULTI TYPE
2, 3, 4 ROOMS TYPE
SPECIFICATIONS3.
COMPACT CASSETTE TYPE3-1.
Model name AU
G07LVLA AU
G09LVLA
AU
G12LVLA
AU
G12LVLB
AU
G14LVLA
AU
G14LVLB
AU
G18LVLA
AU
G18 LVLB
Power source 1ø 230V ~ 50Hz
Available voltage range 198-264V
Capacity 2.0kW Class 2.5kW Class 3.5kW Class 4.0kW Class 5.0kW Class
Input power W 18 18 23 28 39
Running current A 0.15 0.15 0.19 0.22 0.30
Fan
Airow
rate
Cooling
High
m
3
/h
540 540 610 680 750
Med 490 490 530 580 610
Low 440 440 470 490 520
Quiet 390 390 410 410 410
Heating
High 540 540 610 700 800
Med 490 490 530 620 710
Low 440 440 470 550 600
Quiet 390 390 410 430 450
Type × Q'ty Turbo × 1
Motor Output W 42
Sound pressure level *
Cooling
High
dB(A)
33 33 37 40 42
Med 31 31 33 35 37
Low 29 29 31 32 33
Quiet 27 27
28 29 29
Heating
High 34 34 37 40 44
Med 32 32 33 37 40
Low 29 29 31 34 37
Quiet 27 27 28 29 30
Sound power level
Cooling 46 46 49 52 54
Heating 47 47 49 52 56
Heat
exchanger
Dimension (H × W × D)
mm
210 × 1310 × 13.3 + 210 × 1250 × 13.3
Fin pitch 1.2
Rows × Stages 2 × 10
Pipe type Copper tube
Fin Type Aluminium
Dimensions
(H × W × D)
Net
mm
245×570×570
Gross 265×730×625
Weight
Net
kg
15
Gross 18
Connection
pipe
Size
Liquid
mm
Ø6.35 (Ø1/4in.)
Gas Ø9.52 (Ø3/8in.) Ø12.7 (Ø1/2in.)
Method Flare
Operation
range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Drain hose
Material HARD PVC
Size mm Φ25 (I.D.), Φ32 (O.D.)
Cassette
grille
Model name UTG-UF
D-W
Material PS
Colour
WHITE
( Approximate colour of MUNSELL N9.25 )
Dimensions
(H × W × D)
Net
mm
49 × 700 × 700
Gross 120 × 765 × 755
Weight
Net
kg
2.6
Gross 4.5
Remote controller type Wireless [Wired (option)]
NOTE:
The protective function may work when using it outside the operation range.
*: These are the measured values in the manufacturer’s anechoic chamber.
Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than
the specied values here.
