Fujitsu AO*G24LAT3 User Manual

- (03 - 01) -
OUTDOOR UNIT AO

G18-24L3
OUTDOOR UNIT AO

G18-24L3
SPECIFICATIONS1.
The following performance is a value at standard combinations.
STANDARD COMBINATION

AO

G18LAT3 : AS

G07LMCA + AS

G07LMCA + AS

G07LMCA
AO

G24LAT3 : AS

G07LMCA + AS

G07LMCA + AS

G09LMCA
Type
INVERTER MULTI MODELS
HEAT PUMP TYPE
Model name AO

G18L AT3 AO

G24LAT3
Power source 230V ~ 50Hz
Available voltage range 198-264V ~ 50Hz
Capacity
Cooling
Rated
kW 5.4 6.8
Btu/h 18400 23200
Min. - Max.
kW 1.8 - 6.8 1.8 - 8.5
Btu/h 6100 - 23200 6100 - 29000
Heating
Rated
kW 6.8 8.0
Btu/h 23200 27300
Min. - Max.
kW 2.0 - 8.0 2.0 - 9.2
Btu/h 6800 - 27300 6800 - 31400
Input power
Cooling
Rated
kW
1.35 1.94
Max. 2.06 2.60
Heating
Rated 1.62 2.00
Max. 2.06 2.87
Current
Cooling
Rated A
5.9 8.5
Heating 7.1 8.8
EER Cooling
Rated kW/kW
4.00 3.51
COP Heating 4.20 4.00
Starting current A 7.1 8.8
Maximum operating current A 9.0 12.5
Fan
Airow rate
Cooling
m
3
/h
3050 3300
Heating 2750 3300
Type x Q'ty Propeller × 1
Motor output W 100
Sound pressure level *1
Cooling
dB(A)
46 48
Heating 47 49
Heat
exchanger
type
Dimension (H × W × D)
mm
672 × 900 × 36.4
Fin pitch 1.45
Rows x Stages 2 × 32
Pipe type Copper tube
Fin type Aluminium
Compressor
Type x Q'ty DC TWIN ROTARY × 1
Motor output W 1100
Refrigerant
Type (Global Warming Potential) R410A (1975)
Charge g 2200
Refrigerant oil Type POE
Enclosure
Material Steel sheet
Colour
BEIGE
(Approximate colour of MUNSELL 10YR7.5 / 1.0NN)
Dimensions
H ×W ×D
Net
mm
700 × 900 × 330
Gross 835 × 1050 × 445
Weight
Net
kg
55
Gross 63
Connection pipe
Size
Liquid
mm
Ø6.35 (Ø1/4 in.) × 3
Gas Ø9.52 (Ø3/8 in.) × 2, [Ø12.70 (Ø1/2 in.) × 1]

2
Method Flare
Pre-charge length (Total)
m
30
Max. length (Total) 50
Max. length (Each) 25
Min. length (Total) 15
Min. length (Each) 5
Max. height difference between
Outdoor Unit and each Indoor Units.
15
Max. height difference between
Indoor Units.
10
Operation range
Cooling
°C
-10 to 46
Heating -15 to 24
NOTE:
Specications are based on the following conditions.
Cooling: Indoor temperature of 27 °CDB / 19 °CWB.and outdoor temperature of 35 °CDB / 24 °CWB.
Heating: Indoor temperature of 20 °CDB / 15 °CWB.and outdoor temperature of 7 °CDB / 6 °CWB.
Pipe length: 5 m, Height difference: 0 m. (Outdoor unit - indoor unit)
The protective function might work when using it outside the operation range.
*1: These are the measured values in the manufacturer’s anechoic chamber.
Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specied
values here.
*2: Connect to connection valve by the adapter
