MODEL: AO
G24L3
Cooling
z
Combination
of indoor unit
COOLING OPERATION
Cooling Capacity
Input Power
(min-max)
EER
Seasonal Data
Room 1 Room 2 Room 3
Total Capacity
(min-max)
Pdesign
SEER
Energy
Efciency
Class
KW KW KW KW KW kW
2 Room
7 7 - 2.30 2.30 - 4.60 ( 1.8 - 5.0 ) 1.20 ( 0.50 - 1.40 ) 3.83 4.6 6.3 A++
7 9 - 2.30 2.70 - 5.00 ( 1.8 - 5.7 ) 1.36 ( 0.50 - 1.78 ) 3.68 5.0 6.2 A++
7 12 - 2.38 3.42 - 5.80 ( 1.8 - 6.1 ) 1.70 ( 0.50 - 1.97 ) 3.41 5.8 6.1 A++
7 14 - 2.37 4.13 - 6.50 ( 1.8 - 7.2 ) 1.91 ( 0.50 - 2.46 ) 3.40 6.5 6.0 A+
7 18 - 2.08 4.52 - 6.60 ( 1.8 - 7.8 ) 1.91 ( 0.50 - 2.87 ) 3.46 6.6 5.9 A+
9 9 - 2.75 2.75 - 5.50 ( 1.8 - 6.2 ) 1.55 ( 0.50 - 2.02 ) 3.55 5.5 6.1 A++
9 12 - 2.79 3.41 - 6.20 ( 1.8 - 6.8 ) 1.90 ( 0.50 - 2.45 ) 3.26 6.2 5.9 A+
9 14 - 2.66 3.94 - 6.60 ( 1.8 - 7.7 ) 1.91 ( 0.50 - 2.77 ) 3.46 6.6 6.0 A+
9 18 - 2.35 4.35 - 6.70 ( 1.8 - 7.9 ) 1.91 ( 0.50 - 2.87 ) 3.51 6.7 5.9 A+
12 12 - 3.15 3.15 - 6.30 ( 1.8 - 7.2 ) 1.90 ( 0.50 - 2.74 ) 3.32 6.3 5.9 A+
12 14 - 3.03 3.67 - 6.70 ( 1.8 - 7.8 ) 1.91 ( 0.50 - 2.87 ) 3.51 6.7 5.9 A+
12 18 - 2.66 4.04 - 6.70 ( 1.8 - 7.9 ) 1.92 ( 0.50 - 2.87 ) 3.49 6.7 5.8 A+
3 Room
7 7 7 2.23 2.23 2.23 6.70 ( 1.8 - 7.4 ) 1.89 ( 0.50 - 2.37 ) 3.54 6.7 6.4 A++
7 7 9 2.14 2.14 2.52 6.80 ( 1.8 - 7.8 ) 1.94 ( 0.60 - 2.87 ) 3.51 6.8 6.4 A++
7 7 12 1.98 1.98 2.84 6.80 ( 1.8 - 8.1 ) 1.93 ( 0.50 - 2.87 ) 3.52 6.8 6.3 A++
7 7 14 1.82 1.82 3.16 6.80 ( 2.0 - 8.4 ) 1.94 ( 0.60 - 2.87 ) 3.51 6.8 6.2 A++
7 7 18 1.63 1.63 3.54 6.80 ( 2.0 - 8.5 ) 1.94 ( 0.60 - 2.87 ) 3.51 6.8 6.1 A++
7 9 9 2.03 2.38 2.38 6.80 ( 1.8 - 8.2 ) 1.93 ( 0.50 - 2.87 ) 3.52 6.8 6.4 A++
7 9 12 1.88 2.21 2.70 6.80 ( 1.8 - 8.2 ) 1.93 ( 0.50 - 2.87 ) 3.52 6.8 6.2 A++
7 9 14 1.74 2.04 3.02 6.80 ( 2.0 - 8.4 ) 1.94 ( 0.60 - 2.87 ) 3.51 6.8 6.2 A++
7 9 18 1.56 1.84 3.40 6.80 ( 2.0 - 8.5 ) 1.94 ( 0.60 - 2.87 ) 3.51 6.8 6.1 A++
7 12 12 1.76 2.52 2.52 6.80 ( 1.8 - 8.2 ) 1.94 ( 0.50 - 2.87 ) 3.51 6.8 6.2 A++
7 12 14 1.63 2.34 2.83 6.80 ( 2.0 - 8.5 ) 1.94 ( 0.60 - 2.87 ) 3.51 6.8 6.2 A++
9 9 9 2.27 2.27 2.27 6.80 ( 1.8 - 8.2 ) 1.94 ( 0.50 - 2.87 ) 3.51 6.8 6.4 A++
9 9 12 2.11 2.11 2.58 6.80 ( 1.8 - 8.3 ) 1.94 ( 0.50 - 2.87 ) 3.51 6.8 6.2 A++
9 9 14 1.95 1.95 2.89 6.80 ( 2.0 - 8.5 ) 1.94 ( 0.60 - 2.87 ) 3.51 6.8 6.2 A++
9 9 18*1 1.77 1.77 3.27 6.80 ( 2.0 - 8.5 ) 1.94 ( 0.60 - 2.87 ) 3.51 6.8 6.1 A++
9 12 12 1.97 2.41 2.41 6.80 ( 1.8 - 8.3 ) 1.94 ( 0.50 - 2.87 ) 3.51 6.8 6.2 A++
9 12 14 1.84 2.24 2.72 6.80 ( 2.0 - 8.5 ) 1.94 ( 0.60 - 2.87 ) 3.51 6.8 6.2 A++
12 12 12 2.27 2.27 2.27 6.80 ( 1.8 - 8.3 ) 1.94 ( 0.50 - 2.87 ) 3.51 6.8 6.1 A++
Notes:
7: 7000Btu/h, 9: 9000Btu/h, 12: 12000Btu/h ,14:14000Btu/h ,18:18000Btu/h models.
•
The above is the value for connecting with Wall Mounted type.
•
2 or more indoor units should be connected.
•
Cooling capacity is based on 27 °CDB / 19 °CWB (indoor temperature), 35 °CDB (outdoor temperature).
•
Pipe length : 5m, Height difference : 0m. (Outdoor unit to indoor unit)
•
The total ability of connected a indoor unit is up to 36000 Btu from 14000 Btu.
•
1: When "AS
G18L" is connected, connect at least 1 wall mounted type of 9000Btu.
