Fujitsu AO*G24LAT3 User Manual

- (03 - 08) -
OUTDOOR UNIT AO

G18-24L3
OUTDOOR UNIT AO

G18-24L3
Heating
z
Combination
of indoor unit
HEATING OPERATION
Heating Capacity
Input Power
(min-max)
COP
Seasonal Data
Room 1 Room 2 Room 3
Total Capacity
(min-max)
Pdesign
SCOP
Energy
Efciency
Class
KW KW KW KW KW kW
2 Room
7 7 - 2.75 2.75 - 5.50 ( 2.0 - 6.1 ) 1.55 ( 0.52 - 1.93 ) 3.55 4.0 4.1 A+
7 9 - 2.80 3.30 - 6.10 ( 2.0 - 7.0 ) 1.82 ( 0.52 - 2.52 ) 3.35 4.0 4.1 A+
7 12 - 2.88 4.12 - 7.00 ( 2.0 - 7.3 ) 2.31 ( 0.52 - 2.66 ) 3.03 4.0 4.1 A+
7 14 - 2.80 4.80 - 7.60 ( 2.0 - 8.3 ) 2.28 ( 0.50 - 2.87 ) 3.33 4.0 4.1 A+
7 18 - 2.51 5.39 - 7.90 ( 2.0 - 8.3 ) 2.34 ( 0.50 - 2.87 ) 3.38 4.0 4.1 A+
9 9 - 3.30 3.30 - 6.60 ( 2.0 - 7.4 ) 2.04 ( 0.52 - 2.68 ) 3.24 4.0 4.1 A+
9 12 - 3.30 4.00 - 7.30 ( 2.0 - 7.7 ) 2.43 ( 0.52 - 2.87 ) 3.00 4.0 4.1 A+
9 14 - 3.22 4.68 - 7.90 ( 2.0 - 8.3 ) 2.38 ( 0.50 - 2.87 ) 3.32 4.0 4.1 A+
9 18 - 2.84 5.16 - 8.00 ( 2.0 - 8.5 ) 2.32 ( 0.50 - 2.87 ) 3.45 4.0 4.1 A+
12 12 - 3.80 3.80 - 7.60 ( 2.0 - 7.8 ) 2.54 ( 0.52 - 2.87 ) 2.99 4.0 4.1 A+
12 14 - 3.59 4.31 - 7.90 ( 2.0 - 8.4 ) 2.37 ( 0.50 - 2.87 ) 3.33 4.0 4.1 A+
12 18 - 3.20 4.80 - 8.00 ( 2.0 - 8.6 ) 2.31 ( 0.50 - 2.87 ) 3.46 4.0 4.1 A+
3 Room
7 7 7 2.60 2.60 2.60 7.80 ( 2.0 - 8.6 ) 1.94 ( 0.50 - 2.68 ) 4.02 5.0 4.3 A+
7 7 9 2.52 2.52 2.96 8.00 ( 2.0 - 8.8 ) 2.00( 0.50 - 2.87 ) 4.00 5.2 4.2 A+
7 7 12 2.34 2.34 3.32 8.00 ( 2.0 - 8.9 ) 1.99 ( 0.50 - 2.80 ) 4.02 5.2 4.2 A+
7 7 14 2.16 2.16 3.68 8.00 ( 2.0 - 9.2 ) 1.91 ( 0.50 - 2.72 ) 4.19 5.2 4.2 A+
7 7 18 1.94 1.94 4.12 8.00 ( 2.0 - 9.2 ) 1.89 ( 0.50 - 2.70 ) 4.23 5.2 4.2 A+
7 9 9 2.38 2.81 2.81 8.00( 2.0 - 9.0 ) 1.99 ( 0.50 - 2.87 ) 4.02 5.2 4.2 A+
7 9 12 2.23 2.62 3.15 8.00 ( 2.0 - 9.1 ) 1.98 ( 0.50 - 2.87 ) 4.04 5.2 4.2 A+
7 9 14 2.06 2.42 3.52 8.00 ( 2.0 - 9.2 ) 1.91 ( 0.50 - 2.72 ) 4.19 5.2 4.2 A+
7 9 18 1.85 2.18 3.97 8.00 ( 2.0 - 9.2 ) 1.89 ( 0.50 - 2.69 ) 4.23 5.2 4.2 A+
7 12 12 2.08 2.96 2.96 8.00 ( 2.0 - 9.1 ) 1.97 ( 0.50 - 2.87 ) 4.06 5.2 4.2 A+
7 12 14 1.93 2.76 3.31 8.00 ( 2.0 - 9.2 ) 1.90 ( 0.50 - 2.70 ) 4.21 5.2 4.2 A+
9 9 9 2.67 2.67 2.67 8.00 ( 2.0 - 9.1 ) 1.98 ( 0.50 - 2.87 ) 4.04 5.2 4.2 A+
9 9 12 2.49 2.49 3.02 8.00 ( 2.0 - 9.2 ) 1.97 ( 0.50 - 2.87 ) 4.06 5.2 4.2 A+
9 9 14 2.32 2.32 3.37 8.00 ( 2.0 - 9.2 ) 1.89 ( 0.50 - 2.70 ) 4.23 5.2 4.2 A+
9 9 18*1 2.10 2.10 3.81 8.00 ( 2.0 - 9.2 ) 1.87 ( 0.50 - 2.68 ) 4.28 5.2 4.2 A+
9 12 12 2.34 2.83 2.83 8.00 ( 2.0 - 9.2 ) 1.96 ( 0.50 - 2.80 ) 4.08 5.2 4.2 A+
9 12 14 2.18 2.64 3.17 8.00 ( 2.0 - 9.2 ) 1.89 ( 0.50 - 2.69 ) 4.23 5.2 4.2 A+
12 12 12 2.67 2.67 2.67 8.00 ( 2.0 - 9.2 ) 1.95 ( 0.50 - 2.78 ) 4.10 5.2 4.2 A+
Notes:
7: 7000Btu/h, 9: 9000Btu/h, 12: 12000Btu/h ,14:14000Btu/h, 18:18000Btu/h models.

•
The above is the value for connecting with Wall Mounted type.

•
2 or more indoor units should be connected.

•
Heating capacity is based on 20 °CDB (indoor temperature), 7 °CDB / 6 °CWB (outdoor temperature).

•
Pipe length : 5m, Height difference : 0m. (Outdoor unit to indoor unit)

•
The total ability of connected a indoor unit is up to 36000 Btu from 14000 Btu.

•

1: When "AS

G18L" is connected, connect at least 1 wall mounted type of 9000Btu.
