- (02 - 04) -
OUTDOOR UNIT
AO
G14-18L2
OUTDOOR UNIT
AO
G14-18L2
INSTALLATION PLACE
(Unit : mm)
When there are obstacles at the
back side.
When there are obstacles at the back
or front sides.
*If the space is larger that is stated, the condition
will be the same as that are no obstacles.
When there are obstacles at the back, side(s), and top. When there are obstacles at the back, side
with the installation of more than one unit.
