Fujitsu AO*G24LAT3 User Manual

- (03 - 23) -
OUTDOOR UNIT AO

G18-24L3
OUTDOOR UNIT AO

G18-24L3
Indoor unit : 9000Btu + 12000Btu + 12000Btu
z
Indoor unit : 9000Btu + 12000Btu + 14000Btu
z
Indoor unit : 12000Btu + 12000Btu + 12000Btu
z
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
IP : Input Power (kW)
Indoor temperature
°CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB
°CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB
9+12+12
Outdoor temperature
(°CDB) TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10 6.69 5 .18 1.18 7.45 5.21 1.19 7.70 5.66 1.20 8.21 5.68 1.21 8.46 6.14 1.22 8.97 6.11 1.23 9.22 6.10 1.24
-5 6.41 5.05 1.33 7.14 5.08 1.35 7.3 8 5.52 1.36 7.87 5.55 1.37 8.11 5.99 1.38 8.60 5.97 1.40 8.84 5.95 1.40
0 6.30 5.00 1.47 7.01 5.03 1.49 7.25 5.47 1.50 7.73 5.49 1.52 7.97 5.93 1.52 8.45 5.90 1.54 8.69 5.89 1.55
5 6.24 4.97 1.51 6.95 5.01 1.53 7.19 5.44 1.54 7.66 5.46 1.56 7.90 5.90 1.56 8.37 5.87 1.58 8.61 5.86 1.59
10 6.30 5.00 1.53 7.01 5.03 1.55 7.25 5.47 1.56 7.73 5.49 1.58 7.97 5.93 1.58 8.45 5.90 1.60 8.69 5.89 1.61
15 6.81 5.23 1.99 7.59 5.27 2.02 7.84 5.72 2.03 8.36 5.75 2.05 8.62 6.20 2.06 9.14 6.18 2.08 9.40 6.17 2.09
20 7.54 5.55 2.35 8.40 5.59 2.38 8.69 6.07 2.39 9.26 6.10 2.42 9.55 6.58 2.43 10.12 6.56 2.46 10.41 6.55 2.47
25 7.31 5.45 2.38 8.14 5.49 2.41 8.42 5.96 2.42 8.97 5.99 2.45 9.25 6.46 2.46 9.81 6.44 2.49 10.08 6.43 2.50
30 6.93 5.29 2.61 7.72 5.32 2.65 7.9 8 5.78 2.66 8.51 5.80 2.69 8.77 6.26 2.70 9.30 6.24 2.73 9.56 6.23 2.75
35 6.56 5 .12 2.77 7.30 5.15 2.87 7.5 5 5.60 2.87 8.05 5.62 2.87 8.30 6.07 2.87 8.80 6.05 2.87 9.05 6.03 2.87
40 5.47 4.61 2.32 6.09 4.64 2.40 6.30 5.04 2.40 6.71 5.06 2.40 6.92 5.46 2.40 7. 3 4 5.44 2.40 7.54 5.43 2.40
46 4.04 4.04 1.88 4.51 4.09 1.88 4.66 4.44 1.88 4.97 4.46 1.88 5.12 4.81 1.88 5.43 4.79 1.88 5.58 4.79 1.88
Indoor temperature
°CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB
°CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB
9+12+14
Outdoor temperature
(°CDB) TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10 7.14 5.63 1.29 7.96 5.67 1.31 8.23 6.16 1.31 8.77 6.18 1.33 9.04 6.68 1.33 9.59 6.65 1.35 9.86 6.64 1.35
-5 6.85 5.50 1.46 7.63 5.53 1.48 7. 8 9 6.01 1.49 8.41 6.03 1.50 8.67 6.51 1.51 9 .19 6.49 1.53 9.45 6.48 1.53
0 6.73 5.44 1.61 7.49 5.48 1.63 7.75 5.95 1.64 8.26 5.97 1.66 8.52 6.45 1.67 9.03 6.42 1.68 9.28 6.41 1.69
5 6.67 5.41 1.65 7.43 5.45 1.68 7.68 5.92 1.69 8.19 5.94 1.70 8.44 6.41 1.71 8.95 6.39 1.73 9.20 6.38 1.74
10 7.16 5.64 1.91 7. 98 5.68 1.94 8.25 6.17 1.95 8.80 6.19 1.97 9.07 6.69 1.98 9.61 6.66 2.00 9.89 6.65 2.01
15 7.08 5.60 2.05 7.88 5.64 2.08 8.15 6 .13 2.09 8.69 6.15 2.11 8.96 6.64 2.12 9.50 6.62 2.15 9.77 6.60 2.16
20 7.73 5.89 2.35 8.61 5.93 2.38 8.90 6.45 2.39 9.49 6.47 2.42 9.78 6.99 2.43 10.37 6.96 2.46 10.66 6.95 2.47
25 7.48 5.79 2.38 8.34 5.82 2.41 8.62 6.33 2.42 9.19 6.35 2.45 9.47 6.86 2.46 10.04 6.83 2.49 10.33 6.82 2.50
30 7.09 5.61 2.61 7.90 5.65 2.65 8.17 6.14 2.66 8.71 6 .16 2.69 8.98 6.65 2.70 9.52 6.63 2.73 9.79 6.61 2.75
35 6.72 5.43 2.77 7.48 5.47 2.87 7.74 5.94 2.87 8.25 5.97 2.87 8.50 6.44 2.87 9.01 6.42 2.87 9.27 6.41 2.87
40 5.60 4.89 2.32 6.24 4.92 2.40 6.45 5.35 2.40 6.87 5.37 2.40 7.09 5.80 2.40 7.51 5.78 2.40 7.73 5.76 2.40
46 4.14 4.14 1.88 4.61 4.34 1.88 4.77 4.71 1.88 5.09 4.73 1.88 5.24 5.11 1.88 5.56 5.09 1.88 5.71 5.08 1.88
Indoor temperature
°CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB
°CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB
12+12+12
Outdoor temperature
(°CDB) TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10 6.98 5.36 1.29 7.77 5.40 1.31 8.04 5.87 1.31 8.57 5.89 1.33 8.83 6.36 1.33 9.36 6.33 1.35 9.63 6.32 1.35
-5 6.69 5.23 1.46 7.4 5 5.27 1.48 7.70 5.72 1.49 8.21 5.75 1.50 8.46 6.20 1.51 8.97 6.18 1.53 9.22 6.17 1.53
0 6.57 5 .18 1.61 7. 3 2 5.21 1.63 7.57 5.67 1.64 8.07 5.69 1.66 8.32 6.14 1.67 8.81 6.12 1.68 9.06 6.11 1.69
5 6.51 5.15 1.65 7.25 5.19 1.68 7.5 0 5.64 1.69 7. 99 5.66 1.70 8.24 6.11 1.71 8.74 6.09 1.73 8.98 6.07 1.74
10 6.84 5.30 1.82 7. 62 5.34 1.85 7.8 8 5.80 1.86 8.40 5.82 1.88 8.66 6.28 1.89 9.17 6.26 1.91 9.43 6.25 1.92
15 6.91 5.34 2.05 7.70 5.37 2.08 7.9 6 5.83 2.09 8.49 5.86 2.11 8.75 6.32 2.12 9.27 6.30 2.15 9.54 6.29 2.16
20 7.54 5.61 2.35 8.40 5.65 2.38 8.69 6.14 2.39 9.26 6.16 2.42 9.55 6.65 2.43 10.12 6.63 2.46 10.41 6.62 2.47
25 7.31 5.51 2.38 8 .14 5.55 2.41 8.42 6.03 2.42 8.97 6.05 2.45 9.25 6.53 2.46 9.81 6.51 2.49 10.08 6.50 2.50
30 6.93 5.34 2.61 7.72 5.38 2.65 7.9 8 5.84 2.66 8.51 5.87 2.69 8.77 6.33 2.70 9.30 6.31 2.73 9.56 6.30 2.75
35 6.56 5.17 2.77 7.30 5.21 2.87 7.55 5.66 2.87 8.05 5.68 2.87 8.30 6.13 2.87 8.80 6.11 2.87 9.05 6.10 2.87
40 5.47 4.66 2.32 6.09 4.69 2.40 6.30 5.09 2.40 6.71 5.11 2.40 6.92 5.52 2.40 7. 34 5.50 2.40 7.54 5.49 2.40
46 4.04 4.04 1.88 4.51 4.13 1.88 4.66 4.49 1.88 4.97 4.51 1.88 5.12 4.86 1.88 5.43 4.85 1.88 5.58 4.84 1.88

Fujitsu AO*G24LAT3 Specifications

General

Brand	Fujitsu
Model	AO*G24LAT3
Category	Air Conditioner
Language	English
