Fujitsu AO*G24LAT3 User Manual

- (04 - 09) -
OUTDOOR UNIT AO

G30L4
OUTDOOR UNIT AO

G30L4
Combination
of indoor unit
HEATING OPERATION
Heating Capacity
Input Power
(min-max)
COP
Seasonal Data
Room 1 Room 2 Room 3 Room 4
Total Capacity
(min-max)
Pdesign
SCOP
Energy
Efciency
Class
KW KW KW KW KW KW kW
4 Room
7 7 7 7 2.35 2.35 2.35 2.35 9.40 ( 1.8 - 10.8 ) 2.43 ( 0.58 - 3.47 ) 3.87 6.2 4.0 A+
7 7 7 9 2.27 2.27 2.27 2.68 9.50 ( 1.8 - 10.9 ) 2.42 ( 0.58 - 3.51 ) 3.88 6.2 4.0 A+
7 7 7 12 2.14 2.14 2.14 3.06 9.50 ( 1.8 - 11.1 ) 2.41 ( 0.58 - 3.55 ) 3.94 6.2 4.0 A+
7 7 7 14 2.04 2.04 2.04 3.49 9.60 ( 3.3 - 11.3 ) 2.38 ( 0.87 - 3.56 ) 4.03 6.2 4.0 A+
7 7 7 18 1.87 1.87 1.87 4.00 9.60 ( 3.3 - 12.0 ) 2.27 ( 0.87 - 3.56 ) 4.23 6.2 4.0 A+
7 7 9 9 2.18 2.18 2.57 2.57 9.50 ( 3.3 - 10.9 ) 2.41 ( 0.87 - 3.44 ) 3.94 6.2 4.0 A+
7 7 9 12 2.06 2.06 2.43 2.95 9.50 ( 3.3 - 11.1 ) 2.40 ( 0.87 - 3.54 ) 3.96 6.2 4.0 A+
7 7 9 14 1.96 1.96 2.31 3.36 9.60 ( 3.3 - 11.4 ) 2.38 ( 0.87 - 3.54 ) 4.03 6.2 4.0 A+
7 7 9 18 1.80 1.80 2.13 3.87 9.60 ( 3.7 - 12.0 ) 2.27 ( 0.97 - 3.55 ) 4.23 6.2 4.0 A+
7 7 12 12 1.98 1.98 2.82 2.82 9.60 ( 3.3 - 11.3 ) 2.39 ( 0.87 - 3.57 ) 4.02 6.2 4.0 A+
7 7 12 14 1.87 1.87 2.67 3.20 9.60 ( 3.3 - 11.5 ) 2.36 ( 0.87 - 3.58 ) 4.07 6.2 4.0 A+
7 7 12 18 1.72 1.72 2.46 3.69 9.60 ( 3.7 - 12.0 ) 2.27 ( 0.97 - 3.58 ) 4.23 6.2 4.0 A+
7 7 14 14 1.77 1.77 3.03 3.03 9.60 ( 3.7 - 11.8 ) 2.34( 0.97 - 3.58 ) 4.10 6.2 4.0 A+
7 7 14 18 1.64 1.64 2.81 3.51 9.60 ( 3.7 - 12.0 ) 2.27 ( 0.97 - 3.56 ) 4.23 6.2 4.0 A+
7 9 9 9 2.09 2.47 2.47 2.47 9.50 ( 3.3 - 11.2 ) 2.40 ( 0.87 - 3.54 ) 4.00 6.2 4.0 A+
7 9 9 12 2.01 2.36 2.36 2.87 9.60 ( 3.3 - 11.3 ) 2.39( 0.87 - 3.58 ) 4.02 6.2 4.0 A+
7 9 9 14 1.89 2.23 2.23 3.25 9.60 ( 3.7 - 11.5 ) 2.37 ( 0.97 - 3.58 ) 4.05 6.2 4.0 A+
7 9 9 18 1.75 2.06 2.06 3.74 9.60 ( 3.7 - 12.0 ) 2.27 ( 0.97 - 3.58 ) 4.23 6.2 4.0 A+
7 9 12 12 1.91 2.25 2.72 2.72 9.60 ( 3.3 - 11.4 ) 2.38 ( 0.87 - 3.58 ) 4.03 6.2 4.0 A+
7 9 12 14 1.80 2.13 2.58 3.09 9.60 ( 3.7 - 11.6 ) 2.35 ( 0.97 - 3.58 ) 4.09 6.2 4.0 A+
7 9 12 18 1.67 1.97 2.39 3.58 9.60 ( 3.7 - 12.0 ) 2.27 ( 0.97 - 3.58 ) 4.23 6.2 4.0 A+
7 9 14 14 1.71 2.02 2.94 2.94 9.60 ( 3.7 - 11.8 ) 2.33 ( 0.97 - 3.58 ) 4.12 6.2 4.0 A+
7 9 14 18 1.59 1.87 2.73 3.41 9.60 ( 4.3 - 12.0 ) 2.27 ( 1.12 - 3.58 ) 4.23 6.2 4.0 A+
7 12 12 12 1.81 2.59 2.59 2.59 9.60 ( 3.3 - 11.5 ) 2.37 ( 0.87 - 3.58 ) 4.05 6.2 4.0 A+
7 12 12 14 1.72 2.46 2.46 2.95 9.60 ( 3.7 - 11.7 ) 2.34 ( 0.97 - 3.58 ) 4.10 6.2 4.0 A+
7 12 12 18 1.60 2.29 2.29 3.43 9.60 ( 3.7 - 12.0 ) 2.27 ( 0.97 - 3.56 ) 4.23 6.2 4.0 A+
7 12 14 14 1.64 2.34 2.81 2.81 9.60 ( 3.7 - 11.9 ) 2.32 ( 0.97 - 3.58 ) 4.14 6.2 4.0 A+
9 9 9 9 2.40 2.40 2.40 2.40 9.60 ( 3.7 - 11.3 ) 2.40 ( 0.97 - 3.58 ) 4.00 6.2 4.0 A+
9 9 9 12 2.28 2.28 2.28 2.76 9.60 ( 3.7 - 11.4 ) 2.38 ( 0.97 - 3.58 ) 4.03 6.2 4.0 A+
9 9 9 14 2.16 2.16 2.16 3.14 9.60 ( 3.7 - 11.6 ) 2.36 ( 0.97 - 3.58 ) 4.07 6.2 4.0 A+
9 9 9 18*1 1.99 1.99 1.99 3.62 9.60 ( 4.3 - 12.0 ) 2.27 ( 1.12 - 3.58 ) 4.23 6.2 4.0 A+
9 9 12 12 2.17 2.17 2.63 2.63 9.60 ( 3.7 - 11.5 ) 2.37 ( 0.97 - 3.58 ) 4.05 6.2 4.0 A+
9 9 12 14 2.06 2.06 2.49 2.99 9.60 ( 3.7 - 11.7 ) 2.35 ( 0.97 - 3.58 ) 4.09 6.2 4.0 A+
9 9 12 18*2 1.91 1.91 2.31 3.47 9.60 ( 4.3 - 12.0 ) 2.27 ( 1.12 - 3.58 ) 4.23 6.2 4.0 A+
9 9 14 14 1.96 1.96 2.84 2.84 9.60 ( 4.3 - 11.9 ) 2.33 ( 1.12 - 3.58 ) 4.12 6.2 4.0 A+
9 12 12 12 2.07 2.51 2.51 2.51 9.60 ( 3.7 - 11.6 ) 2.36 ( 0.97 - 3.58 ) 4.07 6.2 4.0 A+
9 12 12 14 1.97 2.39 2.39 2.87 9.60 ( 3.7 - 11.8 ) 2.34 ( 0.97 - 3.58 ) 4.10 6.2 4.0 A+
9 12 14 14 1.87 2.27 2.73 2.73 9.60 ( 4.3 - 11.9 ) 2.31 ( 1.12 - 3.58 ) 4.16 6.2 4.0 A+
12 12 12 12 2.40 2.40 2.40 2.40 9.60 ( 3.7 - 11.6 ) 2.35 ( 0.97 - 3.58 ) 4.09 6.2 4.0 A+
Notes:
7:7000Btu/h, 9:9000Btu/h, 12:12000Btu/h, 14:14000Btu/h, 18:18000Btu/h, 24:24000Btu/h models. •
The above is the value for connecting with Wall Mounted type. •
3 or more indoor units should be connected. •
Heating capacity is based on 20 °CDB (indoor temperature), 7 °CDB/6 °CWB (outdoor temperature). •
Pipe l • ength : 5m, Height difference : 0m. (Outdoor unit to indoor unit)
The total ability of connected a indoor unit is up to 49000 Btu from 27000 Btu. •

1: Connection of "AR

G09L+AR

G09L+AR

G09L+AS

G18L " is not available. All types other than this combination can be connected.

2: Connection of "AR

G09L+AR

G09L+AR

G12 L+A S

G18L " is not available. All types other than this combination can be connected.

Fujitsu AO*G24LAT3 Specifications

General

Brand	Fujitsu
Model	AO*G24LAT3
Category	Air Conditioner
Language	English
