- (04 - 12) -
OUTDOOR UNIT AO

G30L4
OUTDOOR UNIT AO

G30L4
Note: 3 or more indoor units should be connected.
Indoor unit : 7000Btu + 12000Btu
z
Indoor unit : 7000Btu + 14000Btu
z
Indoor unit : 7000Btu + 18000Btu
z
Indoor unit : 7000Btu + 24000Btu
z
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
IP : Input Power (kW)
Indoor temperature
°CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB
°CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB
7+12
Outdoor temperature
(°CDB) TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
0 4.58 3.50 0.84 5.11 3.52 0.86 5.28 3.83 0.86 5.63 3.84 0.87 5.80 4.15 0.88 6 .15 4 .14 0.88 6.33 4.13 0.89 6.50 4.40 0.89
5 4.29 3.37 0.97 4.78 3.39 0.98 4.94 3.68 0.99 5.27 3.70 1.00 5.43 3.99 1.00 5.76 3.98 1.01 5.92 3.97 1.02 6.08 4.24 1.02
10 4.25 3.35 1.14 4.74 3.37 1.16 4.90 3.67 1.16 5.22 3.68 1.18 5.38 3.97 1.18 5.71 3.96 1.19 5.87 3.95 1.20 6.03 4.21 1.21
15 4.26 3.35 1.03 4.74 3.37 1.05 4.90 3.67 1.05 5.22 3.68 1.06 5.39 3.97 1.07 5.71 3.96 1.08 5.87 3.95 1.08 6.03 4.22 1.09
20 4.73 3.57 1.31 5.27 3.59 1.33 5.45 3.90 1.34 5.81 3.92 1.35 5.99 4.23 1.36 6.35 4.21 1.37 6.53 4.21 1.38 6.71 4.49 1.39
25 4.56 3.49 1.29 5.08 3.51 1.31 5.25 3.82 1.31 5.60 3.83 1.33 5.77 4.14 1.33 6.12 4.12 1.35 6.29 4.12 1.35 6.47 4.39 1.36
30 4.22 3.34 1.41 4.70 3.36 1.43 4.86 3.65 1.44 5.18 3.66 1.46 5.34 3.95 1.46 5.66 3.94 1.48 5.82 3.93 1.48 5.98 4.20 1.49
35 4.90 3.64 2.12 5.46 3.67 2.16 5.64 3.99 2 .17 6.01 4.00 2.19 6.20 4.32 2.20 6.57 4.30 2.22 6.76 4.30 2.23 6.94 4.58 2.24
40 4.60 3.50 2.55 5.13 3.52 2.59 5.30 3.83 2.60 5.65 3.84 2.63 5.83 4.15 2.64 6.18 4.13 2.67 6.35 4.12 2.68 6.53 4.40 2.69
46 3.68 3.16 1.90 4.10 3.18 1.93 4.24 3.45 1.94 4.52 3.47 1.96 4.66 3.74 1.97 4.94 3.73 1.99 5.08 3.72 2.00 5.22 3.97 2.01
Indoor temperature
°CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB
°CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB
7+14
Outdoor temperature
(°CDB) TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
0 4.62 3.87 0.88 5.15 3.90 0.90 5.32 4.24 0.90 5.67 4.25 0.91 5.85 4.59 0.92 6.20 4.57 0.93 6.37 4.57 0.93 6.55 4.87 0.93
5 4.31 3.73 1.00 4.81 3.76 1.02 4.97 4.08 1.02 5.30 4.10 1.03 5.46 4.42 1.04 5.79 4.41 1.05 5.95 4.40 1.06 6.12 4.69 1.06
10 4.31 3.73 1.18 4.80 3.75 1.20 4.96 4.08 1.20 5.29 4.09 1.21 5.45 4.42 1.22 5.78 4.40 1.23 5.94 4.39 1.24 6 .10 4.69 1.24
15 4.78 3.95 1.12 5.32 3.97 1.14 5.50 4.32 1.15 5.87 4.33 1.16 6.05 4.68 1.16 6.41 4.66 1.17 6.59 4.65 1.18 6.77 4.96 1.19
20 6.09 4.56 1.47 6.79 4.59 1.49 7.0 2 4.98 1.50 7.4 8 5.00 1.51 7.71 5.40 1.52 8.17 5.38 1.54 8.40 5.37 1.54 8.64 5.73 1.55
25 5.86 4.45 1.66 6.53 4.48 1.69 6.75 4.87 1.70 7. 20 4.89 1.72 7.42 5.28 1.72 7. 87 5.26 1.74 8.09 5.25 1.75 8.31 5.60 1.76
30 5.42 4.25 1.82 6.04 4.27 1.85 6.25 4.65 1.86 6.66 4.66 1.88 6.87 5.03 1.89 7. 28 5.02 1.90 7. 48 5.01 1.91 7. 69 5.34 1.92
35 5.61 4.33 2.41 6.25 4.36 2.45 6.46 4.74 2.46 6.89 4.76 2.49 7.10 5.14 2.50 7. 53 5.12 2.53 7.74 5.11 2.54 7. 95 5.45 2.55
40 5.05 4.07 2.65 5.63 4.09 2.70 5.82 4.45 2.71 6.21 4.47 2.74 6.40 4.82 2.75 6.78 4.80 2.78 6.97 4.79 2.79 7.17 5.11 2.81
46 3.75 3.30 2.13 4.17 3.32 2.17 4.32 3.60 2.18 4.60 3.62 2.20 4.74 3.91 2.21 5.03 3.89 2.23 5.17 3.88 2.24 5.31 4.14 2.25
Indoor temperature
°CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB
°CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB
7+18
Outdoor temperature
(°CDB) TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
0 5.70 4.55 1.17 6.34 4.58 1.19 6.56 4.98 1.20 6.99 5.00 1.21 7. 21 5.40 1.21 7. 64 5.38 1.23 7. 86 5.37 1.23 8.07 5.73 1.24
5 5.31 4.38 1.31 5.91 4.41 1.33 6 .11 4.79 1.34 6.52 4.81 1.35 6.72 5.19 1.36 7.12 5.18 1.37 7. 3 2 5.17 1.38 7. 53 5.51 1.38
10 5.36 4.40 1.52 5.97 4.43 1.55 6.17 4.82 1.55 6.58 4.84 1.57 6.78 5.22 1.58 7.19 5.20 1.59 7. 39 5.19 1.60 7. 60 5.54 1.61
15 6.86 5.07 1.45 7. 64 5.10 1.48 7.91 5.55 1.48 8.43 5.57 1.50 8.69 6.01 1.51 9.21 5.99 1.52 9.47 5.98 1.53 9.73 6.38 1.54
20 6.98 5.12 1.66 7.78 5 .16 1.69 8.04 5.60 1.70 8.57 5.63 1.72 8.84 6.07 1.72 9.37 6.05 1.74 9.63 6.04 1.75 9.90 6.44 1.76
25 6.69 4.99 1.92 7.4 5 5.03 1.95 7.70 5.46 1.96 8.21 5.48 1.98 8.47 5.92 1.99 8.97 5.90 2.01 9.23 5.89 2.02 9.48 6.28 2.03
30 6 .19 4.77 2.09 6.90 4.80 2 .13 7.13 5.22 2.14 7. 60 5.24 2.16 7. 84 5.66 2.17 8.31 5.64 2 .19 8.54 5.63 2.20 8.78 6.00 2.21
35 6.48 4.90 2.75 7. 22 4.93 2.79 7. 46 5.36 2.81 7. 95 5.38 2.84 8.20 5.81 2.85 8.69 5.79 2.88 8.94 5.78 2.89 9.18 6.16 2.91
40 5.51 4.40 3.16 6.14 4.43 3.20 6.35 4.81 3.22 6.77 4.83 3.25 6.98 5.21 3.27 7. 40 5.19 3.30 7.61 5.18 3.32 7. 82 5.53 3.34
46 3.87 3.57 2.26 4.32 3.59 2.29 4.46 3.91 2.30 4.76 3.92 2.33 4.90 4.23 2.34 5.20 4.22 2.36 5.34 4.21 2.38 5.49 4.49 2.39
Indoor temperature
°CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB
°CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB
7+24
Outdoor temperature
(°CDB) TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
0 6.99 5.37 1.79 7.78 5.41 1.82 8.05 5.88 1.82 8.58 5.90 1.84 8.84 6.37 1.85 9.37 6.35 1.87 9.64 6.33 1.88 9.91 6.76 1.89
5 6.54 5.18 1.95 7. 28 5.22 1.98 7. 53 5.67 1.99 8.03 5.69 2.01 8.28 6.14 2.02 8.77 6.12 2.05 9.02 6 .11 2.06 9.27 6.52 2.07
10 6.66 5.23 1.62 7. 42 5.27 1.64 7.6 7 5.72 1.65 8 .18 5.75 1.67 8.43 6.20 1.68 8.93 6.18 1.69 9.19 6.17 1.70 9.44 6.58 1.71
15 7. 28 5.50 1.86 8 .11 5.53 1.89 8.38 6.01 1.89 8.94 6.04 1.91 9.21 6.51 1.92 9.77 6.49 1.94 10.04 6.48 1.95 10.32 6.91 1.96
20 7.92 5.77 2.10 8.82 5.81 2.13 9.13 6.31 2.14 9.73 6.33 2.16 10.03 6.84 2.18 10.63 6.81 2.20 10.93 6.80 2.21 11.23 7. 26 2.22
25 7. 5 2 5.60 2.48 8.37 5.63 2.52 8.66 6.12 2.54 9.23 6.15 2.56 9.52 6.63 2.57 10.09 6.61 2.60 10.37 6.60 2.61 10.66 7.04 2.63
30 6.98 5.37 2.69 7.7 7 5.40 2.73 8.04 5.87 2.75 8.57 5.89 2.78 8.83 6.36 2.79 9.36 6.34 2.82 9.63 6.33 2.83 9.89 6.75 2.85
35 7. 35 5.53 3.45 8.18 5.56 3.51 8.46 6.04 3.53 9.02 6.07 3.58 9.30 6.55 3.58 9.86 6.53 3.58 10.14 6.51 3.58 10.42 6.95 3.58
40 5.97 4.86 3.16 6.65 4.89 3.20 6.87 5.32 3.22 7.3 2 5.34 3.25 7.5 5 5.76 3.27 8.00 5.74 3.30 8.23 5.73 3.32 8.46 6.11 3.34
46 4.06 3.98 2.26 4.53 4.01 2.29 4.68 4.36 2.30 4.99 4.37 2.33 5.14 4.72 2.34 5.45 4.71 2.36 5.61 4.70 2.38 5.76 5.01 2.39
