Fujitsu AO*G24LAT3 User Manual

- (04 - 57) -
OUTDOOR UNIT AO

G30L4
OUTDOOR UNIT AO

G30L4
Indoor unit : 7000Btu + 7000Btu + 14000Btu + 14000Btu
z
Indoor unit : 7000Btu + 7000Btu + 14000Btu + 18000Btu
z
Indoor unit : 7000Btu + 9000Btu + 9000Btu + 9000Btu
z
Indoor unit : 7000Btu + 9000Btu + 9000Btu + 12000Btu
z
TC : Total Capacity (kW)
IP : Input Power (kW)
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
7+7+14+14
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-10 -11 7.93 3.13 7.74 3.19 7.55 3.26 7.36 3.32 7.17 3.39
-5 -7 8.92 3.26 8.71 3.33 8.50 3.40 8.28 3.47 8.07 3.54
0 -2 10.28 3.44 10.04 3.51 9.79 3.58 9.55 3.58 9.30 3.58
5 3 11.58 3.44 11.31 3.51 11.03 3.58 10.76 3.58 10.48 3.58
7 6 12.39 3.44 12.10 3.51 11.80 3.58 11.51 3.58 11.21 3.58
10 8 12.89 3.44 12.58 3.51 12.27 3.58 11.97 3.58 11.66 3.58
15 10 12.82 3.20 12.52 3.26 12.21 3.33 11.91 3.34 11.60 3.34
20 15 10.90 2.21 10.64 2.30 10.38 2.30 10.12 2.30 9.86 2.30
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
7+7+14+18
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-10 -11 8.06 3.11 7.87 3.17 7.68 3.24 7.49 3.30 7.30 3.37
-5 -7 9.07 3.25 8.86 3.31 8.64 3.38 8.42 3.45 8.21 3.52
0 -2 10.46 3.42 10.21 3.49 9.96 3.56 9.71 3.58 9.46 3.58
5 3 11.78 3.44 11.50 3.51 11.22 3.58 10.94 3.58 10.66 3.58
7 6 12.60 3.44 12.30 3.51 12.00 3.58 11.70 3.58 11.40 3.58
10 8 13.10 3.44 12.79 3.51 12.48 3.58 12.17 3.58 11.86 3.58
15 10 13.04 3.18 12.73 3.24 12.42 3.31 12.11 3.34 11.80 3.34
20 15 11.09 2.21 10.82 2.30 10.56 2.30 10.30 2.30 10.03 2.30
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
7+9+9+9
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-10 -11 7.88 3.23 7.69 3.30 7.50 3.36 7.32 3.43 7.13 3.50
-5 -7 8.70 3.33 8.50 3.40 8.29 3.47 8.08 3.54 7.87 3.58
0 -2 9.88 3.40 9.64 3.47 9.41 3.54 9.17 3.58 8.94 3.58
5 3 10.94 3.40 10.68 3.47 10.42 3.54 10.16 3.58 9.90 3.58
7 6 11.76 3.40 11.48 3.47 11.20 3.54 10.92 3.58 10.64 3.58
10 8 12.23 3.40 11.94 3.47 11.65 3.54 11.36 3.58 11.07 3.58
15 10 12.17 3.16 11.88 3.23 11.59 3.29 11.30 3.34 11.01 3.34
20 15 10.35 2.21 10.10 2.30 9.86 2.30 9.61 2.30 9.36 2.30
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
7+9+9+12
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-10 -11 7.59 3.13 7.41 3.19 7.23 3.26 7.05 3.32 6.87 3.39
-5 -7 8.54 3.26 8.34 3.33 8.14 3.40 7.93 3.47 7.73 3.54
0 -2 9.85 3.44 9.61 3.51 9.38 3.58 9.14 3.58 8.91 3.58
5 3 11.09 3.44 10.83 3.51 10.57 3.58 10.30 3.58 10.04 3.58
7 6 11.87 3.44 11.58 3.51 11.30 3.58 11.02 3.58 10.74 3.58
10 8 12.34 3.44 12.05 3.51 11.75 3.58 11.46 3.58 11.16 3.58
15 10 12.28 3.20 11.99 3.26 11.70 3.33 11.40 3.34 11.11 3.34
20 15 10.44 2.21 10.19 2.30 9.94 2.30 9.70 2.30 9.45 2.30
