- (01-54) -
MULTI TYPE
2, 3, 4 ROOMS TYPE
MULTI TYPE
2, 3, 4 ROOMS TYPE
MAINTENANCE SPACE
Provide a service access for inspection purposes as shown below.
Do not place any wiring or illumination in the service space, as they will impede service.
Service access
Unit
Control
box
or more
Service space
300
300
or more
100
or more
Unit : mm
