- (01-85) -
MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
Note: This data is measured installing the Auto louver grille kit(option).
Air velocity distribution
z
Side view
Vertical airow direction louver:
Down
Horizontal airow direction louver:
Center
109876543210 (m)
Unit: m/s
0
1
2
2.5
3
(m)
0.5
1
2
Air temperature distribution
z
Side view
Vertical airow direction louver:
Down
Horizontal airow direction louver:
Center
109876543210 (m)
Unit: °C
0
1
2
2.5
3
(m)
30
28
26
24
22
Reference Data
Conditions
Fan speed: HIGH
Operation mode: HEATING
