21
22
28
29
26
25
24
30
23
27
INDOOR UNIT
232012.06.13
30 Sirocco Fan
29 Casing B
28 Casing A 9372057018
9372059029
9372058015
23
Motor, DC Brushless 960308601527
Motor Mount Assy 9380216001
22 Bracket Motor Assy
21 Panel Fan Assy 9372035009
9372037010
26 RFM Motor Band 9378003019
25 Motor Band
24 Motor Band Assy 9378033016
9378031012
Description Parts numberRef.
