1. ETERNUS DX Installation
This chapter provides the installation specification of the ETERNUS DX.
Installation Specifications
ETERNUS DX8100 S3
The following table shows the installation specifications of the ETERNUS DX8100 S3.
Table 1 ETERNUS DX8100 S3 Installation Specifications
Item ETERNUS DX8100 S3
Dimensions
(W ´ D ´ H)
Controller enclosure
482 ´ 809 ´ 133mm (3U)
Drive enclosure 2.5" type
482 ´ 540 ´ 88mm (2U)
3.5" type
482 ´ 560 ´
88mm (2U)
Power distribution unit (*1) Horizontal type
485 ´ 280 ´ 43mm ´ 2 (2U) (*2),
485 ´ 123 ´ 44mm ´ 2 (2U) (*3)
Maximum weight Controller enclosure 54kg
Drive enclosure (*4) 2.5" type 35kg
3.5" type 35kg
Power distribution unit (*1) Horizontal type
(6.0kg) ´
2 (*2),
(3.0kg) ´ 2 (*3)
Power Voltage AC 100 – 120V, AC 200 – 240V
Phase Single
Frequency 50Hz/60Hz
Maximum power
consumption
Controller enclosure AC 100 – 120V 870W (880VA)
AC 200 – 240V 870W (880VA)
Drive enclosure
(*4)
2.5" type AC 100 – 120V 430W (440VA)
AC 200 – 240V 430W (440VA)
3.5" type AC 100 – 120V 340W (350VA)
AC 200 – 240V 340W (350VA)
Maximum heat
generation
Controller enclosure AC 100 – 120V 3,120kJ/h
AC 200 – 240V 3,120kJ/h
Drive enclosure
(*4)
2.5" type AC 100 – 120V 1,600kJ/h
AC 200 – 240V 1,600kJ/h
3.5" type AC 100 – 120V 1,300kJ/h
AC 200 – 240V 1,300kJ/h
Maximum
amount of ex-
haust air
Controller enclosure
6.2m
3
/min
Drive enclosure (*4) 2.5" type
4.0m
3
/min
3.5" type
4.0m
3
/min
10
FUJITSU Storage ETERNUS DX8100 S3/DX8700 S3/DX8900 S3 Hybrid Storage Systems
Site Planning Guide
Copyright 2020 FUJITSU LIMITED
P3AM-9422-13ENZ0
